Danfoss VLT 2840 General Information

Logic and [2]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Clockwise
1 1 Counter-clockwise
Logic or [3]
Dig. input
Ser. port Function
0 0 Clockwise
0 1 Counter-clockwise
1 0 Counter-clockwise
1 1 Counter-clockwise
507 Selection of Setup
(SETUP SELECT)
Value:
Digital input (DIGITAL INPUT) [0]
Serial communication (SERIAL PORT) [1]
Logic and (LOGIC AND) [2]
Logic or (LOGIC OR) [3]
Function:
See function description of parameter 502 Coasting
stop.
Description of choice:
The table below shows which Setup (parameter 004
Active Setup) is selected for each of the following: Dig-
ital input [0], Serial communication [1], Logic and [2] or
Logic or [3].
Digital input [0]
Setup msb
Setup lsb Function
0 0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
Serial communication [1]
Setup msb
Setup lsb Function
0 0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
Logic and [2]
Bus Set-
up
msb
Bus Set-
up
lsb
Dig. Set-
up
msb
Dig. Set-
up
lsb
Setup no.
0 0 0 0 1
0
0 0 1 1
0
0 1 0 1
0
0 1 1 1
0 1 0 0 1
0
1 0 1 2
0
1 1 0 1
0
1 1 1 2
1 0 0 0 1
1
0 0 1 1
1
0 1 0 3
1
0 1 1 3
1 1 0 0 1
1
1 0 1 2
1
1 1 0 3
1
1 1 1 4
Logic or [3]
Bus Set-
up
msb
Bus Set-
up
lsb
Dig. Set-
up
msb
Dig. Set-
up
lsb
Setup no.
0 0 0 0 1
0
0 0 1 2
0
0 1 0 3
0
0 1 1 4
0 1 0 0 2
0
1 0 1 2
0
1 1 0 4
0
1 1 1 4
1 0 0 0 3
1
0 0 1 4
1
0 1 0 3
1
0 1 1 4
1 1 0 0 4
1
1 0 1 4
1
1 1 0 4
1
1 1 1 4
VLT
®
2800 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.27.A2.22 - VLT
®
is a registered Danfoss trademark 87
Programming
