25MG.30.A7.02 - VLT
®
is a registered Danfoss trademark
Mains supply 3 x 380/400/415 V Technical data
According to international VDE and UL/CSA requirements VLT
type 3060 3075 3100 3125 3150 3200 3250
Constant torque (CT):
Output current I
VLT,N
[A] 86 105 139 168 205 243 302
I
VLT,MAX
[A] (60s) 129 158 209 252 308 365 453
Output S
VLT,N
[kVA] 61.8 73 96 116 142 168 209
S
VLT,MAX
(60s) 89 109 144 175 213 253 314
Typical shaft output P
VLT,N
[kW] 45 55 75 90 110 132 160
Quadratic torque (VT):
Output current I
VLT,N
[A] 105 139 168 205 243 302 368
I
VLT,MAX
[A] (60s) 116 153 185 226 267 332 405
Output S
VLT,N
[kVA] 73 96 116 142 168 209 255
Typical shaft output P
VLT,N
[kW] 55 75 90 110 132 160 200
Max. cable cross-section [mm
2
] 70 70 150 150 150 2x95 2x95
Max. motor cable length [m] 300
Output voltage U
M
[%] 0-100 of mains voltage
Output frequency f
M
[Hz] 0-120 or 0-500, programmable
Rated motor voltage U
M,N
[V] 380/400/415/440/460/500
Rated motor frequency f
M,N
[Hz] 50/60/87/100
Thermal protection during operation Integrated thermal motor protection (electronic);
thermistor to DIN 44081
Switching on output Unlimited (frequent switching on output may result in fault message)
Ramp times [s] 0.1 - 3600
VLT
Type 3060 3075 3100 3125 3150 3200 3250
Input current I
L,N
[A] 84.6 103.3 138.4 167.2 201.7 241.9 307.6
I
L,MAX
(60s) [A] 129.0 158.0 209.0 252.0 308.0 365.0 453.0
Quadratic load I
L,N
[A] 103.3 138.4 167.2 201.7 241.9 293.3 366.3
I
L,MAX
(60s) [A] 116.0 153.0 185.0 226.0 267.0 332.0 405.0
Max. cable cross-section [mm
2
] 120.0 120.0 2 x 120 2 x 120 2 x 120 2 x 240 2 x 240
Pre-fuses
1)
[A] 150.0 150.0 250.0 250.0 300.0 450.0 500.0
Supply voltage (VDE 0160) [V] 3 x 380/400/415/440/460/500 ±10%
Supply frequency [Hz] 50/60
Power factor / cos. ϕ
1
0.9/1.0
Efficiency 0,96 at 100% load
Switching on input times/min. 1
VLT type 3060 3075 3100 3125 3150 3200 3250
Weight (kg)
IP 21 147 147 211 211 220 306 306
IP 54 147 147 211 211 220 306 306
Power loss at max. load CT [W]
Front 423 529 713 910 1091 1503 1812
Heat sink 859 1074 1447 1847 2216 3051 3679
Power loss at max. load VT [W]
Front 529 713 910 1091 1503 1812 2209
Heat sink 1074 1447 1847 2216 3051 3679 4485
Enclosure IP 21 / IP 54 NEMA 1/12
Vibration test [g] 0.7
Relative humidity [%] VDE 0160 5.2.1.2.
Ambient temperature [°C] -10→ +40 operation at full load (VT) -10→ +45 (CT)
2)
(to VDE 0160) [°C] -30/25→ +65/70 in storage/transport
Frequency converter protection Protection against earthing and short-circuiting
EMC standards Emission EN 55011, EN 55014
(See section “EMC test results”) Immunity EN 50082-2, IEC 1000-4-2, IEC 1000-4-3, IEC 1000-4-4,
IEC 1000-4-5, VDE 0160
1) Bussman rapid type JJS integrated.
2) In the range -10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will not fulfil the
specifications.
