83MG.30.A7.02 - VLT
®
is a registered Danfoss trademark
Parameter description 0.. Operation and display
✮ = Factory setting. Text in ( ) = Display text.
The figures in [ ] are used in bus communication.
002
Setup copy
(Menu set copy)
Value:
✭ No copy (Do not copy) [0]
Copy to 1 from # (
COPY TO 1 FROM #) [1]
Copy to 2 from # (copy to 2 from #) [2]
Copy to 3 from # (copy to 3 from #) [3]
Copy to 4 from # (copy to 4 from #) [4]
Copy to ALL from # (copy all from ) [5]
Function:
A menu setup can be copied to one of the
other setups, or all other setups simultane-
ously, but not to setup [0].
Copying can only take place in Stop Mode.
Description of choices:
Copying begins when the required data
value has been entered, and the data
mode is left by pressing MENU or auto-
matically after 20 seconds.
Line 3 in the display flashes while copying
is taking place.
The display shows the setup copied to and
from. The active setup is always copied
from (selected in parameter 001 or via the
terminals 16/17 or 32/33).
When copying is completed, the data value
automatically switches to “No copying” [0].
003
Operation site
(Local / remote)
Value:
✭ Remote (remote) [0]
Local with external stop
(loc/ext stop) [1]
Local (local) [2]
Function:
Three modes of operation of the VLT
®
fre-
quency converter can be selected: Remote
control, local with external stop option and
local operation.
Description of choices:
Remote control is selected for control via
the control terminals or serial port (RS485).
The keyboard functions are still active,
assuming that they have not been
deselected in parameter 006-009. Note:
Local reversing is not possible, however,
irrespective of what has been selected in
parameter 008.
Local with external stop is selected to
operate the VLT
®
frequency converter from
the keyboard without using external control
signals but with the possibility of an exter-
nal stop function. The external stop func-
tion must be connected between terminals
12 and 27. A circuit breaker (NC) and
terminal 27 (parameter 404) must be
programmed for freewheeling stop or reset
and freewheeling stop).
Local is selected to exclusively operate the
VLT
®
from the keyboard without any kind of
external control signals (nor RS485).
Note:
For both local selections, speed can be
controlled on parameter 004.
