Danfoss VLT 3002 User Manual

94 MG.30.A7.02 - VLT
®
is a registered Danfoss trademark
✮ = Factory setting. Text in ( ) = Display text.
The figures in [ ] are used in bus communication.
Parameter description 2.. References and limits
200
Frequency range (f
RANGE
)
(Freq range)
Set the maximum of the frequency convert-
er’s output frequency range.
201
Min. frequency (f
MIN
)
(Min frequency)
The output frequency corresponding to the
minimum reference input.
202
Max. frequency (f
MAX
)
(Max frequency)
Value:
f
MIN
- f
RANGE
The output frequency corresponding to the
maximum reference input.
203
JOG frequency
(JOG frequency)
A preset output frequency. The jog fre-
quency can be lower than the minimum
output frequency recorded in parameter
201, but is limited by the f
MAX
setting in
parameter 202. The JOG frequency can be
activated via the keyboard or terminal 29
(para. 405).
Value:
✭ 0 - 120 Hz [0]
0 - 500 Hz [1]
Value:
0,0 - f
MAX
✭ 0,0
Value:
0.0 - f
RANGE
✭10 Hz
204
Digital reference type
(Dig. ref. type)
On selection of sum one of the digital refer-
ences (parameters 205-208) as a percent-
age of f
MAX
is added to the other references.
On selection of
relative one of the digital
references (parameters 205-208) is added
as a percentage of the other references.
On selection of
external on/off none of the
digital references is added.
It is possible to switch between the other
references and one of the digital referen-
ces (parameters 205-208) via terminal 29
(parameter 405).
NB: The sign determines only the running
direction when external to/from is selected.
Other references are the sum of the ana-
logue, pulse and bus references.
One of the digital references is selected via
terminals 32 and 33, (para. 406) cf. the
table below.
Terminal 33/ Terminal 32
0 0 Digital ref. 1
0 1 Digital ref. 2
1 0 Digital ref. 3
1 1 Digital ref. 4
205
Digital reference 1
(REF. 1 digital)
206
Digital reference 2
(REF. 2 digital)
207
Digital reference 3
(REF. 3 digital)
208
Digital reference 4
(REF. 4 digital)
Value:
✭ Sum (sum) [0]
Relative (relative) [1]
External on / off (ext. on / off) [2]
Value:
−100.00% - +100.00% ✭ 0
of f
MAX
/analog ref.
Value:
−100.00% - +100.00% ✭ 0
of f
MAX
/analog ref.
Value:
−100.00% - +100.00% ✭ 0
of f
MAX
/analog ref.
Value:
−100.00% - +100.00% ✭ 0
of f
MAX
/analog ref.
✭ Depending
on unit
