Danfoss VLT 3532 User Manual

RDS 20 DC Controls
VLT
®
Series 3500
21
inches (mm)
D
20.2 (513)
17.0 (432)
59.6
(1515)
Door
Radius
35.2
(894)
57.2
(1453)
20.2
(513)
NEMA 1 15.5 (394)
1.2
(31)
NEMA 12 16.4 (417)
0.5
(13)
Ø0.59
Ø1.06
(27)
(15)
1.3 (32)
2.2
(56)
5.0
(127)
Optional
Pedestal
14.2
(361)
19.5
(495)
1.0 (25.4)
1.0
(25.4)
(4– 1/2" holes
for bolting
pedestal and
VLT to floor)
Optional
Pedestal
VLT 3100
Dimensions
VLT 3625, 3650, 3700, 380 and 460 V
