VLT
®
Series 3500
18
inches (mm)
W
a
b
D
H
d
c
0.33
(8.5)
0.39
(10)
W
a
b
c
0.98
(25)
0.33
(8.5)
Ø0.57
(14.5)
D
H
d
Drawing 1
Type Input Overall Dimensions Mounting Dimensions
VAC H W D a b c d
Chassis 230 37.40 (950) 12.09 (307) 11.65 (296) 10.63 (270) 36.61 (930)
Chassis 380 0.39 (10) 0.39 (10)
Chassis 460
NEMA 1 230 38.89 (975) 12.09 (307) 11.65 (296) 10.63 (270) 36.61 (930) 1.38 (35)
NEMA 1 380 0.39 (10)
NEMA 1 460
Drawing 2
Type Input Overall Dimensions Mounting Dimensions
VAC H W D a b c d
NEMA 12 230 37.01 (940) 15.67 (398) 14.72 (374) 27.17 (690)
NEMA 12 380 11.02 (280) 7.09 (180) 2.76 (70)
NEMA 12 460
VLT 3022
Drawing 1 Drawing 2
VLT 3532 Dimensions
31.50 (800) 9.53 (242) 10.24 (260) 7.87 (200) 29.92 (760) 1.18 (30)
30.71 (780) 9.53 (242) 10.24 (260) 7.87 (200) 29.92 (760)
31.89 (810) 13.78 (350) 12.83 (326) 22.05 (560)
