Danfoss VLT 3542

VLT
®
Series 3500
22
inches (mm)
D
20.2 (513)
66.7
(1694)
Door
Radius
39.7
(1008)
20.2
(513)
NEMA 1 20.0 (508)
NEMA 12 20.9 (531)
2.2
(56)
5.0
(127)
Pedestal
Pedestal
19.5
(495)
19.5
(495)
1.0 (25.4)
1.0
(25.4)
(4– 1/2" holes
for bolting
pedestal and
VLT to floor)
VLT 3250
Dimensions
VLT 3750, 3800, 380 and 460 V
