VLT 5001-5052, 200-240 V units
Typecode designation: T2
Powersize (kW) Type Enclosure HW variant RFI filter
Torque
C00 B20 C20 CN1 C54 ST SB EB R0 R1 R3
110% 160%
9-10 11-13 11-13 11-13 11-13 11-13 14-15 14-15 14-15 16-17 16-17 16-17
0.75 5001 x x x x x x x
1.1 5002 x x x x x x x
1.5 5003 x x x x x x x
2.2 5004 x x x x x x x
3 5005 x x x x x x x
3.7 5006 x x x x x x x
7.5 5.5 5008 x x x x x x x
11 7.5 5011 x x x x x x x
15 11 5016 x x x x x x x
18.5 15 5022 x x x x x x x
22 18.5 5027 x x x x x x x
30 22 5032 x x x x x x x x
37 30 5042 x x x x x x x x
45 37 5052 x xxxxx xx
C00 Compact IP00 DE Extended with brake, disconnect and fuses
B20 Bookstyle IP20 DX Extended without brake, with disconnect and fuses
C20 Compact IP20 PS Standard with 24 V supply
CN1 Compact Nema1 PB Standard with 24 V supply, brake, fuse and disconnect
C54 Compact IP54 PD Standard with 24 V supply, fuse and disconnect
ST Standard PF Standard with 24 V supply and fuse
SB Standard with brake R0 Without filter
EB Extended with brake R1 Class A1 filter
EX Extended without brake R3 Class A1 and B filter
VLT
®
5000 Design Guide
MG.52.B2.02 - VLT
®
is a registered Danfoss trademark 13
How to select your fre-
quency converter
