Danfoss VLT 5152 Operating Instructions

VLT
®
5000 Series
Programming
Outputs terminal no. 42 45 01(relay) 04
(relay)
parameter 319 321 323 326
Value:
0-100 Hz 0-20 mA (0-100 Hz = 0-20 mA) [36] [36]
0-100 Hz 4-20 mA (0-100 Hz = 4-20 mA) [37] [37]
0-100 Hz 0-32000 p (0-100 Hz = 0-32000P) [38] [38]
0-f
MAX
0-20 mA (0-FMAX = 0-20 mA) [39] [39] ✭
0-f
MAX
4-20 mA (0-FMAX = 4-20 mA) [40] [40]
0-f
MAX
0-32000 p (0-FMAX = 0-32000P) [41] [41]
Ref
MIN
-Ref
MAX
0-20 mA (REF MIN-MAX = 0-20 mA) [42] [42]
Ref
MIN
-Ref
MAX
4-20 mA (REF MIN-MAX = 4-20 mA) [43] [43]
Ref
MIN
-Ref
MAX
0-32000 p (REF MIN-MAX = 0-32000P) [44] [44]
FB
MIN
-FB
MAX
0-20 mA (FB MIN-MAX = 0-20 mA) [45] [45]
FB
MIN
-FB
MAX
4-20 mA (FB MIN-MAX = 4-20 mA) [46] [46]
FB
MIN
-FB
MAX
0-32000 p (FB MIN-MAX = 0-32000P) [47] [47]
0-I
MAX
0-20 mA (0-IMAX = 0-20 mA) [48] ✭ [48]
0-I
MAX
4-20 mA (0-IMAX = 4-20 mA) [49] [49]
0-I
MAX
0-32000 p (0-IMAX = 0-32000P) [50] [50]
0-T
LIM
0-20 mA (0-TLIM = 0-20 mA) [51] [51]
0-T
LIM
4-20 mA (0-TLIM = 4-20 mA) [52] [52]
0-T
LIM
0-32000 p (0-TLIM = 0-32000P) [53] [53]
0-T
NOM
0-20 mA (0-TNOM = 0-20 mA) [54] [54]
0-T
NOM
4-20 mA (0-TNOM = 4-20 mA) [55] [55]
0-T
NOM
0-32000 p (0-TNOM = 0-32000P) [56] [56]
0-P
NOM
0-20 mA (0-PNOM = 0-20 mA) [57] [57]
0-P
NOM
4-20 mA (0-PNOM = 4-20 mA) [58] [58]
0-P
NOM
0-32000 p (0-PNOM = 0-32000P) [59] [59]
0-SyncRPM 0-20 mA (0-SYNCRPM = 0-20 mA) [60] [60]
0-SyncRPM 4-20 mA (0-SYNCRPM = 4-20 mA) [61] [61]
0-SyncRPM 0-32000 p (0-0-SYNCRPM = 0-32000 p) [62] [62]
0-RPMatFMAX 0-20 mA (0-RPMFMAX = 0-20 mA) [63] [63]
0-RPMatFMAX 4-20 mA (0-RPMFMAX = 4-20 mA) [64] [64]
0-RPMatFMAX 0-32000 p (0-RPMFMAX = 0-32000 p) [65] [65]
319 Terminal 42, output
(AO 42 FUNCT.)
Function:
This output can act both as a digital and an analogue
output. If used as a digital output (data value
[0]-[65]), a 24 V DC signal is transmitted; if used as
an analogue output either a 0-20 mA signal, a 4-20
mA signal or a pulse output is transmitted.
Description of choice:
Control ready, the frequency converter is ready for
use; the control card receives supply voltage.
Ready signal, the frequency converter control card
is receiving a supply signal and the frequency
converter is ready for operation.
Ready, remote control, the frequency converter control
card is receiving a supply signal and parameter
002 has been set to remote control.
Enable, no warning, the frequency converter is
ready for use; no start or stop command has been
given (start/disable). No warning.
Running is active when there is a start command
or the output frequency is above 0.1 Hz. Is
also active during ramp down.
Running, no warning , the output frequency is higher
than the frequency set in parameter 123. A start
command has been given. No warning.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.51.A9.02 - VLT is a registered Danfoss trademark
131
