Programming
0-100 Hz 0-32000 p,apulseoutput
signal proportional to the output frequency
in the range 0-100 Hz.
0-f
MAX
0-20 mA and
0-f
MAX
4-20 mA and
0-f
MAX
0-32000 p, an output signal proportional
to the output frequency range in the range
0-f
MAX
(parameter 202).
Ref
MIN
-Ref
MAX
0-20 mA and
Ref
MIN
-Ref
MAX
4-20 mA and
Ref
MIN
-Ref
MAX
0-32000 p, an output signal
proportional to the reference value in the interval Ref
MIN
-Ref
MAX
(parameters 204/205) is obtained.
B
MIN
-FB
MAX
0-20 mA and
FB
MIN
-FB
MAX
4-20 mA and
FB
MIN
-FB
MAX
0-32000 p, an output signal
proportional to the feedback value in the interval FB
MIN
-FB
MAX
(parameters 414/415) is obtained.
0-I
VLT, MAX
0-20 mA or
0-I
VLT, MAX
4-20 mA and
0-I
VLT, MAX
0-32000 p, an output signal proportional
to the output current in the interval 0 - I
VLT,MAX
is obtained. I
VLT,MAX
depends on the settings in
parameter 101 and 103 and can be seen from
the Technical data (I
VLT,MAX
(60 s).
0-M
LIM
0-20 mA and
0-M
LIM
4-20 mA and
0-M
LIM
0-32000 p, an output proportional to
the output torque in the interval 0 - T
LIM
(parameter
221) is obtained. 20 mA corresponds to the
value set in parameter 221.
0-M
NOM
0-20 mA and
0-M
NOM
4-20 mA and
0-M
NOM
0-32000 p, an output signal proportional
to the output torque of the motor. 20 mA corresponds
to the rated torque for the motor.
0-P
NOM
0-20 mA and
0-P
NOM
4-20 mA and
0-P
NOM
0-32000 p, 0 - P
NOM
0-32000 p,
an output signal proportional to the rated motor
output is obtained. 20 mA corresponds to the
value set in parameter 102.
0-SyncRPM
0-20 mA and
0-SyncRPM
4-20 mA and
0-SyncRPM
0-32000 p, an output signal
proportional to the synchronous motor RPM is obtained.
0-RPMatF
MAX
0-20 mA and
0-RPMatF
MAX
4-20 mA and
0-RPMatF
MAX
0-32000 p, n output signal
proportional to the synchronous motor RPM at
F
MAX
(parameter 202) is obtained.
320 Terminal 42, output, pulse scaling
(AO 42 PULS SCALE)
Value:
1 - 32000 Hz
✭ 5000 Hz
Function:
This parameter allows scaling of the pulse output signal.
Description of choice:
Set the desired value.
321 Terminal 45, output
(AO 45 FUNCT.)
Value:
See description for parameter 319.
Function:
This output can function both as a digital and an
analogue output. Used as a digital output (data value
[0]-[35]) it generates a 24 V (max. 40 mA) signal; on the
analogue outputs (data value [36]-[59]) there is a choice
of 0-20 mA, 4-20 mA or a scalable pulse output.
Description of choice:
See description for parameter 319.
322 Terminal 45, output, pulse scaling
(AO 45 PULS SCALE)
Value:
1 - 32000 Hz
✭ 5000 Hz
Function:
This parameter allows scaling of the pulse output signal.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
