Technical
data
■ Compact, Mains supply 3 x 380 - 500 V
According to international requirements VLT type 5122 5152 5202 5252 5302
Normal overload current (110 %):
Output current I
VLT,N
[A] (380-440 V) 212 260 315 395 480
I
VLT, MAX
(60 s) [A]
(380-440 V)
233 286 347 434 528
I
VLT,N
[A] (441-500 V) 190 240 302 361 443
I
VLT, MAX
(60 s) [A]
(441-500 V)
209 264 332 397 487
Output S
VLT,N
[kVA] (400 V) 147 180 218 274 333
S
VLT,N
[kVA] (460 V) 151 191 241 288 353
S
VLT,N
[kVA] (500 V) 165 208 262 313 384
Typical shaft output [kW] (400 V) 110 132 160 200 250
[HP] (460 V) 150 200 250 300 350
[kW] (500 V) 132 160 200 250 315
High overload torque (160 %):
Output current I
VLT,N
[A] (380-440 V) 177 212 260 315 395
I
VLT, MAX
(60 s) [A]
(380-440 V)
266 318 390 473 593
I
VLT,N
[A] (441-500 V) 160 190 240 302 361
I
VLT, MAX
(60 s) [A]
(441-500 V)
240 285 360 453 542
Output S
VLT,N
[kVA] (400 V) 123 147 180 218 274
S
VLT,N
[kVA] (460 V) 127 151 191 241 288
S
VLT,N
[kVA] (500 V) 139 165 208 262 313
Typical shaft output [kW] (400 V) 90 110 132 160 200
[HP] (460 V) 125 150 200 250 300
[kW] (500 V) 110 132 160 200 250
Max. cable cross-section
to motor
[mm
2
]
4,6
[AWG]
2,4,6
2x70
2x2/0
2 x 185
2x350mcm
Max. cable cross-section
to loadsharing and brake
[mm
2
]
4,6
[AWG]
2,4,6
2x70
2x2/0
2 x 185
2x350mcm
Normal overload current (110 %):
Rated input current I
L,N
[A] (380-440 V) 208 256 317 385 467
I
L,N
[A] (441-500 V) 185 236 304 356 431
High overload torque (160 %):
Rated input current I
L,N
[A] (380-440 V) 174 206 256 318 389
I
L,N
[A] (441-500 V) 158 185 236 304 356
Max. cable cross-section
power supply
[mm
2
]
4,6
[AWG]
2,4,6
2x70
2x2/0
2 x 185
2x350mcm
Max. pre-fuses (mains)
[-]/UL
[A]
1
300/
300
350/
350
450/
400
500/
500
630/
600
Efficiency
3
0,98
Power loss Normal overload [W] 2619 3309 4163 4977 6107
High overload [W] 2206 2619 3309 4163 4977
Weight IP 00 [kg] 82 91 112 123 138
Weight IP 21/Nema1 [kg] 96 104 125 136 151
Weight IP 54/Nema12 [kg] 96 104 125 136 151
Enclosure IP 00, IP 21/Nema 1 and IP 54/Nema12
1. For type of fuse see section Fuses
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Max. cable cross-section is the maximum possible cable cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
5. Weight without shipping container.
6. Connection bolt power supply and motor: M10; Brake and loadsharing: M8
