Function:
This parameter is used for setting the signal value that
corresponds to the maximum reference value set in
parameter 204.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
310 Terminal 53, max. scaling
(AI 53 SCALE HIGH)
Value:
0.0 - 10.0 Volt
10.0 Volt
Function:
This parameter is used for setting the signal value that
corresponds to the maximum reference value set in
parameter 205.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
311 Terminal 54, analog input voltage
(AI [V] 54 FUNCT.)
Value:
See description of parameter 308
Function:
This parameter chooses between the different func-
tions available for the input, terminal 54.
Scaling of the input signal is effected in parameters
312 and 313.
Description of choice:
See description of parameter 308.
312 Terminal 54, min. scaling
(AI 54 SCALE LOW)
Value:
0.0 - 10.0 Volt
0.0 Volt
Function:
This parameter is used for setting the scaling value
that corresponds to the minimum reference value set
in parameter 204.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
313 Terminal 54, max. scaling
(AI 54 SCALE HIGH)
Value:
0.0 - 10.0 Volt
10.0 Volt
Function:
This parameter is used for setting the signal value that
corresponds to the maximum reference value set in
parameter 205.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
314 Terminal 60, analog input current
(AI [mA] 60 FUNCT)
Value:
See description of parameter 308
Function:
This parameter allows a choice between the different
functions available for the input, terminal 60.
Scaling of the input signal is effected in parameters
315 and 316.
Description of choice:
See description of parameter 308.
315 Terminal 60, min. scaling
(AI 60 SCALE LOW)
Value:
0.0 - 20.0 mA
4 mA
VLT
®
5000 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.51.C5.22 - VLT
p
is a registered Danfoss trademark. 115
Programming
