Outputs terminal no. 42 45 01(relay) 04 (relay)
parameter 319 321 323 326
Value:
0-100 Hz ය 0-20 mA
(0-100 Hz = 0-20 mA) [36] [36]
0-100 Hz ය 4-20 mA
(0-100 Hz = 4-20 mA) [37] [37]
0-100 Hz ය 0-32000 p
(0-100 Hz = 0-32000P) [38] [38]
0 - f
MAX
ය 0-20 mA
(0-FMAX = 0-20 mA) [39]
[39]
0 - f
MAX
ය 4-20 mA
(0-FMAX = 4-20 mA) [40] [40]
0 - f
MAX
ය 0-32000 p
(0-FMAX = 0-32000P) [41] [41]
Ref
MIN
- Ref
MAX
ය 0-20 mA
(REF MIN-MAX = 0-20 mA) [42] [42]
Ref
MIN
- Ref
MAX
ය 4-20 mA
(REF MIN-MAX = 4-20 mA) [43] [43]
Ref
MIN
- Ref
MAX
ය 0-32000 p
(REF MIN-MAX = 0-32000P) [44] [44]
FB
MIN
- FB
MAX
ය 0-20 mA
(FB MIN-MAX = 0-20 mA) [45] [45]
FB
MIN
- FB
MAX
ය 4-20 mA
(FB MIN-MAX = 4-20 mA) [46] [46]
FB
MIN
- FB
MAX
ය 0-32000 p
(FB MIN-MAX = 0-32000P) [47] [47]
0 - I
MAX
ය 0-20 mA
(0-IMAX = 0-20 mA)
[48]
[48]
0 - I
MAX
ය 4-20 mA
(0-IMAX = 4-20 mA) [49] [49]
0 - I
MAX
ය 0-32000 p
(0-IMAX = 0-32000P) [50] [50]
0 - T
LIM
ය 0-20 mA
(0-TLIM = 0-20 mA) [51] [51]
0 - T
LIM
ය 4-20 mA
(0-TLIM = 4-20 mA) [52] [52]
0 - T
LIM
ය 0-32000 p
(0-TLIM = 0-32000P) [53] [53]
0 - T
NOM
ය 0-20 mA
(0-TNOM = 0-20 mA) [54] [54]
0 - T
NOM
ය 4-20 mA
(0-TNOM = 4-20 mA) [55] [55]
0 - T
NOM
ය 0-32000 p
(0-TNOM = 0-32000P) [56] [56]
0 - P
NOM
ය 0-20 mA
(0-PNOM = 0-20 mA) [57] [57]
0 - P
NOM
ය 4-20 mA
(0-PNOM = 4-20 mA) [58] [58]
0 - P
NOM
ය 0-32000 p
(0-PNOM = 0-32000P) [59] [59]
0 - SyncRPM ය 0-20 mA
(0-SYNCRPM = 0-20 mA) [60] [60]
0 -SyncRPM ය 4-20 mA
(0-SYNCRPM = 4-20 mA) [61] [61]
0 - SyncRPM ය 0-32000 p
(0-0-SYNCRPM = 0-32000 p) [62] [62]
0 - RPM at FMAX ය 0-20 mA
(0-RPMFMAX = 0-20 mA) [63] [63]
0 - RPM at FMAX ය 4-20 mA
(0-RPMFMAX = 4-20 mA) [64] [64]
0 - RPM at FMAX ය 0-32000 p
(0-RPMFMAX = 0-32000 p) [65] [65]
319 Terminal 42, output
(AO 42 FUNCT.)
Function:
This output can act both as a digital and an analogue
output. If used as a digital output (data value [0]-[65]),
a 24 V DC signal is transmitted; if used as an analogue
output either a 0-20 mA signal, a 4-20 mA signal or a
pulse output is transmitted.
Description of choice:
Control ready, the frequency converter is ready for use;
the control card receives supply voltage.
Ready signal, the frequency converter control card is
receiving a supply signal and the frequency converter
is ready for operation.
Ready, remote control, the frequency converter control
card is receiving a supply signal and parameter 002
has been set to remote control.
Enable, no warning, the frequency converter is ready
for use; no start or stop command has been given
(start/disable). No warning.
Running is active when there is a start command or the
output frequency is above 0.1 Hz. Is also active during
ramp down.
Running, no warning , the output frequency is higher
than the frequency set in parameter 123. A start com-
mand has been given. No warning.
Runs in range, no warning, runs within the programmed
current/frequency ranges set in parameters 223-226.
VLT
®
5000 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
118 MG.51.C5.22 - VLT
