0-f
MAX
ය 0-20 mA and
0-f
MAX
ය 4-20 mA and
0-f
MAX
ය 0-32000 p, an output signal proportional to
the output frequency range in the range 0 - f
MAX
(pa-
rameter 202).
Ref
MIN
- Ref
MAX
ය 0-20 mA and
Ref
MIN
- Ref
MAX
ය 4-20 mA and
Ref
MIN
- Ref
MAX
ය 0-32000 p, an output signal propor-
tional to the reference value in the interval Ref
MIN
-
Ref
MAX
(parameters 204/205) is obtained.
B
MIN
-FB
MAX
ය 0-20 mA and
FB
MIN
-FB
MAX
ය 4-20 mA and
FB
MIN
-FB
MAX
ය 0-32000 p, an output signal propor-
tional to the feedback value in the interval FB
MIN
-
FB
MAX
(parameters 414/415) is obtained.
0 - I
VLT, MAX
ය 0-20 mA or
0 - I
VLT, MAX
ය 4-20 mA and
0 - I
VLT, MAX
ය 0-32000 p, an output signal proportional
to the output current in the interval 0 - I
VLT,MAX
is ob-
tained. I
VLT,MAX
depends on the settings in parameter
101 and 103 and can be seen from the Technical da-
ta (I
VLT,MAX
(60 s).
0 - M
LIM
ය 0-20 mA and
0 - M
LIM
ය 4-20 mA and
0 - M
LIM
ය 0-32000 p, an output proportional to the
output torque in the interval 0 - T
LIM
(parameter 221) is
obtained. 20 mA corresponds to the value set in pa-
rameter 221.
0 - M
NOM
ය 0-20 mA and
0 - M
NOM
ය 4-20 mA and
0 - M
NOM
ය 0-32000 p, an output signal proportional to
the output torque of the motor. 20 mA corresponds to
the rated torque for the motor.
0 - P
NOM
ය 0-20 mA and
0 - P
NOM
ය 4-20 mA and
0 - P
NOM
ය 0-32000 p, 0 - P
NOM
ය 0-32000 p, an output
signal proportional to the rated motor output is ob-
tained. 20 mA corresponds to the value set in param-
eter 102.
0 - SyncRPM
ය 0-20 mA and
0 - SyncRPM
ය 4-20 mA and
0 - SyncRPM
ය 0-32000 p, an output signal propor-
tional to the synchronous motor RPM is obtained.
0 - RPM at F
MAX
ය 0-20 mA and
0 - RPM at F
MAX
ය 4-20 mA and
0 - RPM at F
MAX
ය 0-32000 p, n output signal propor-
tional to the synchronous motor RPM at F
MAX
(param-
eter 202) is obtained.
320 Terminal 42, output, pulse scaling
(AO 42 PULS SCALE)
Value:
1 - 32000 Hz
5000 Hz
Function:
This parameter allows scaling of the pulse output sig-
nal.
Description of choice:
Set the desired value.
321 Terminal 45, output
(AO 45 FUNCT.)
Value:
See description for parameter 319.
Function:
This output can function both as a digital and an analog
output. Used as a digital output (data value [0]-[35]) it
generates a 24 V (max. 40 mA) signal; on the analog
outputs (data value [36]-[59]) there is a choice of 0-20
mA, 4-20 mA or a scalable pulse output.
Description of choice:
See description for parameter 319.
VLT
®
5000 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
120 MG.51.C5.22 - VLT
p
is a registered Danfoss trademark.
