Danfoss VLT CANopen MCA 105 Instruction Manual

6.3.21 32-** MCO Basic Settings
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion
index
Type
32-0* Encoder 2
32-00 Incremental Signal Type [1] TTL (5V, RS4222) 2 set-ups TRUE - Uint8
32-01 Incremental Resolution 1024 N/A 2 set-ups TRUE 0 Uint32
32-02 Absolute Protocol [0] None 2 set-ups TRUE - Uint8
32-03 Absolute Resolution 8192 N/A 2 set-ups TRUE 0 Uint32
32-04 Absolute Encoder Baudrate X55 [4] 9600 All set-ups FALSE - Uint8
32-05 Absolute Encoder Data Length 25 N/A 2 set-ups TRUE 0 Uint8
32-06 Absolute Encoder Clock Frequency 262 kHz 2 set-ups TRUE 0 Uint32
32-07 Absolute Encoder Clock Generation [1] On 2 set-ups TRUE - Uint8
32-08 Absolute Encoder Cable Length 0 m 2 set-ups TRUE 0 Uint16
32-09 Encoder Monitoring [0] Off 2 set-ups TRUE - Uint8
32-10 Rotational Direction [1] No action 2 set-ups TRUE - Uint8
32-11 User Unit Denominator 1 N/A 2 set-ups TRUE 0 Uint32
32-12 User Unit Numerator 1 N/A 2 set-ups TRUE 0 Uint32
32-13 Enc.2 Control [0] No soft changing 2 set-ups TRUE - Uint8
32-14 Enc.2 node ID 127 N/A 2 set-ups TRUE 0 Uint8
32-15 Enc.2 CAN guard [0] Off 2 set-ups TRUE - Uint8
32-3* Encoder 1
32-30 Incremental Signal Type [1] TTL (5V, RS4222) 2 set-ups TRUE - Uint8
32-31 Incremental Resolution 1024 N/A 2 set-ups TRUE 0 Uint32
32-32 Absolute Protocol [0] None 2 set-ups TRUE - Uint8
32-33 Absolute Resolution 8192 N/A 2 set-ups TRUE 0 Uint32
32-35 Absolute Encoder Data Length 25 N/A 2 set-ups TRUE 0 Uint8
32-36 Absolute Encoder Clock Frequency 262 kHz 2 set-ups TRUE 0 Uint32
32-37 Absolute Encoder Clock Generation [1] On 2 set-ups TRUE - Uint8
32-38 Absolute Encoder Cable Length 0 m 2 set-ups TRUE 0 Uint16
32-39 Encoder Monitoring [0] Off 2 set-ups TRUE - Uint8
32-40 Encoder Termination [1] On 2 set-ups TRUE - Uint8
32-43 Enc.1 Control [0] No soft changing 2 set-ups TRUE - Uint8
32-44 Enc.1 node ID 127 N/A 2 set-ups TRUE 0 Uint8
32-45 Enc.1 CAN guard [0] Off 2 set-ups TRUE - Uint8
32-5* Feedback Source
32-50 Source Slave [2] Encoder 2 2 set-ups TRUE - Uint8
32-51 MCO 302 Last Will [1] Trip 2 set-ups TRUE - Uint8
32-52 Source Master [1] Encoder 1 X56 2 set-ups TRUE - Uint8
32-6* PID Controller
32-60 Proportional factor 30 N/A 2 set-ups TRUE 0 Uint32
32-61 Derivative factor 0 N/A 2 set-ups TRUE 0 Uint32
32-62 Integral factor 0 N/A 2 set-ups TRUE 0 Uint32
32-63 Limit Value for Integral Sum 1000 N/A 2 set-ups TRUE 0 Uint16
32-64 PID Bandwidth 1000 N/A 2 set-ups TRUE 0 Uint16
32-65 Velocity Feed-Forward 0 N/A 2 set-ups TRUE 0 Uint32
32-66 Acceleration Feed-Forward 0 N/A 2 set-ups TRUE 0 Uint32
32-67 Max. Tolerated Position Error 20000 N/A 2 set-ups TRUE 0 Uint32
32-68 Reverse Behavior for Slave [0] Reversing allowed 2 set-ups TRUE - Uint8
32-69 Sampling Time for PID Control 1 ms 2 set-ups TRUE -3 Uint16
32-70 Scan Time for Profile Generator 1 ms 2 set-ups TRUE -3 Uint8
32-71 Size of the Control Window (Activation) 0 N/A 2 set-ups TRUE 0 Uint32
32-72 Size of the Control Window (Deactiv.) 0 N/A 2 set-ups TRUE 0 Uint32
32-73 Integral limit filter time 0 ms 2 set-ups TRUE -3 Int16
32-74 Position error filter time 0 ms 2 set-ups TRUE -3 Int16
32-8* Velocity & Accel.
32-80 Maximum Velocity (Encoder) 1500 RPM 2 set-ups TRUE 67 Uint32
32-81 Shortest Ramp 1 s 2 set-ups TRUE -3 Uint32
32-82 Ramp Type [0] Linear 2 set-ups TRUE - Uint8
32-83 Velocity Resolution 100 N/A 2 set-ups TRUE 0 Uint32
32-84 Default Velocity 50 N/A 2 set-ups TRUE 0 Uint32
Programming Instruction Manual
104 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
