Danfoss VLT CANopen MCA 105 Instruction Manual

6.3 Parameter Lists - Adjustable Frequency
Drive
Changes during operation
True means that the parameter can be changed while the
adjustable frequency drive is in operation and false means
that it must be stopped before making a change.
4-Set-up
'All set-up': the parameters can be set individually in each
of the four set-ups, i.e., one single parameter can have four
different data values.
’1 set-up’: data value is the same in all set-ups.
Conversion index
This number refers to a conversion figure used when
writing or reading to and from the adjustable frequency
drive.
Conv. index Conv. factor
100 1
67 1/60
6 1000000
5 100000
4 10000
3 1000
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
-6 0.000001
Table 6.11 Conversion Index
Data
type
Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 Boolean variables V2
54 Time difference w/o date TimD
Table 6.12 Data Types
See the adjustable frequency drive Design Guide for further
information about data types 33, 35 and 54.
6.3.1
Parameter Selection
Parameters for the adjustable frequency drive are grouped
into various parameter groups for easy selection of the
correct parameters for optimized operation of the
adjustable frequency drive.
0-** Operation and display parameters for basic adjustable
frequency drive settings
1-** Load and motor parameters, includes all load and
motor related parameters
2-** Brake parameters
3-** References and ramping parameters, includes DigiPot
function
4-** Limits/Warnings, setting of limits and warning
parameters
5-** Digital inputs and outputs, includes relay controls
6-** Analog inputs and outputs
7-** Controllers, setting parameters for speed and process
controls
8-** Communication and option parameters, setting of FC
RS-485 and FC USB port parameters.
9-** Profibus parameters
Programming
Instruction Manual
78 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
66
