Danfoss VLT CANopen MCA 105 Instruction Manual

6.4.2 5-** Digital In/Out
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
5-0* Digital I/O mode
5-00 Digital I/O mode [0] PNP All set-ups FALSE - Uint8
5-01 Terminal 27 mode [0] Input All set-ups TRUE - Uint8
5-02 Terminal 29 mode [0] Input All set-ups x TRUE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 digital input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 digital input [0] No operation All set-ups TRUE - Uint8
5-12 Terminal 27 digital input [0] No operation All set-ups TRUE - Uint8
5-13 Terminal 29 digital input [0] No operation All set-ups TRUE - Uint8
5-19 Terminal 37 safe stop [1] Safe Stop Alarm 1 set-up TRUE - Uint8
5-3* Digital Outputs
5-30 Terminal 27 digital output [0] No operation All set-ups TRUE - Uint8
5-31 Terminal 29 digital output [0] No operation All set-ups x TRUE - Uint8
5-4* Relays
5-40 Function relay [0] No operation All set-ups TRUE - Uint8
5-41 On delay, relay 0.30 s All set-ups TRUE -2 Uint16
5-42 Off delay, relay 0.30 s All set-ups TRUE -2 Uint16
Programming Instruction Manual
MG37A222 Danfoss A/S © Rev. 2014-02-07 All rights reserved. 111
