6.3.14 13-** Smart Logic
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
13-0* SLC Settings
13-00 SL Controller Mode ExpressionLimit 2 set-ups TRUE - Uint8
13-01 Start Event ExpressionLimit 2 set-ups TRUE - Uint8
13-02 Stop Event ExpressionLimit 2 set-ups TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC All set-ups TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand ExpressionLimit 2 set-ups TRUE - Uint8
13-11 Comparator Operator ExpressionLimit 2 set-ups TRUE - Uint8
13-12 Comparator Value ExpressionLimit 2 set-ups TRUE -3 Int32
13-1* RS Flip Flops
13-15 RS-FF Operand S ExpressionLimit 2 set-ups TRUE - Uint8
13-16 RS-FF Operand R ExpressionLimit 2 set-ups TRUE - Uint8
13-2* Timers
13-20 SL Controller Timer ExpressionLimit 1 set-up TRUE -3 TimD
13-4* Logic Rules
13-40 Logic Rule Boolean 1 ExpressionLimit 2 set-ups TRUE - Uint8
13-41 Logic Rule Operator 1 ExpressionLimit 2 set-ups TRUE - Uint8
13-42 Logic Rule Boolean 2 ExpressionLimit 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 ExpressionLimit 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 ExpressionLimit 2 set-ups TRUE - Uint8
13-5* States
13-51 SL Controller Event ExpressionLimit 2 set-ups TRUE - Uint8
13-52 SL Controller Action ExpressionLimit 2 set-ups TRUE - Uint8
Programming Instruction Manual
96 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
