525-690 Volt
VLT Type P200 P250 P315 P355
Output current [VAC] HO NO HO NO HO NO HO NO
Continuous (100/ 100%) [A] 550 253 303 303 360 360 418 395 470
Intermittent (150/ 110%) [A] 550 380 333 455 396 540 460 593 517
Continuous (100/ 100%) [A] 575/ 690 242 290 290 344 344 400 380 450
Intermittent (150/ 110%) [A] 575/ 690 363 319 435 378 516 440 570 495
Output kVA
Continuous (100/ 100%) [kVA] 550 241 289 289 343 343 398 376 448
Intermittent (150/ 110%) [kVA] 550 362 318 433 377 514 438 564 493
Continuous (100/ 100%) [kVA] 575 241 289 289 343 343 398 378 448
Intermittent (150/ 110%) [kVA] 575 362 318 433 377 514 438 568 493
Continuous (100/ 100%) [kVA] 690 289 347 347 411 411 478 454 538
Intermittent (150/ 110%) [kVA] 690 434 381 520 452 617 526 681 592
Typical Shaft Output
High Overload (150%) [kW] 550 160 200 250 315
Normal Overload (110%) [kW] 550 200 250 315 355
High Overload (150%) [HP] 575 250 300 350 400
Normal Overload (110%) [HP] 575 300 350 400 450
High Overload (150%) [kW] 690 200 250 315 355
Normal Overload (110%) [kW] 690 250 315 400 450
Max. Motor Cable Length 500 ft (150 m) shielded, 1,000 ft (300 m) unshiel-
ded
Output Voltage [%] 0-100% of the AC line voltage
Output Frequency [Hz] 0-200 0-150
Rated Motor Voltage [V] 550/ 575/ 690
Rated Motor Frequency [Hz] 50/60
Thermal protection during
operation
ETR for motor (Class 20)
Thermal protection during
operation
110 110 110 85
Switching on the Output Unlimited
Ramp times [sec] 0.01 - 3600
