525-690 Volt
VLT Type P200 P250 P315 P355
Max. Input Current [A] 550 245 299 299 355 355 408 381 453
Max. Input Current [A] 575 234 286 286 339 339 390 366 434
Max. Input Current [A] 690 240 296 296 352 352 400 366 434
Max. external pre-fuses
1)
[A]
400 500 600 700
Soft Charge Fuses
2)
AC [A]
(qty)
20 (3)
SMPS fuse
3)
[A]
4
AC Fan fuse
3)
[A]
4
Supply Voltage [V] 3 Phase, 525-690 ± 10%
Supply Frequency [Hz] 50/ 60
Power Factor >0.90 for 525 V, >0.85 for 690 V
Efficiency 0.98
Power loss at rated max. load (690 V)
High Overload (150%) [W] 4275 4875 5185 5383
Normal Overload (110%) [W] 5156 5821 6149 6449
Enclosure
IP 00, IP 21/ NEMA 1 & IP 54/ NEMA 12
Vibration Test [g] 0.7
Relative Humidity [%] 93%, +2%, -3% (IEC 68-2-3)
Ambient Temperature [de-
grees C]
-10° C to 40° C [14°-104° F] continuously, peri-
odically at +45° C [113° F]
-25° C to +65°/70° C [-13°-149°/158° F] for stor-
age/ transport
Adjustable Frequency Drive
Protection
Ground and short-circuit protection
Weight
5)
IP 00/ Chassis [kg]
122.9 137.7 151.3 221
IP 21/ NEMA 1 [kg] 136.3 151.3 164.9 263
IP 54/ NEMA 12 [kg]
136.3 151.3 164.9 263
1) Bussman 170M6000 series. See fuse chart.
2) Bussmann FWH-20A6F or exact equivalent, 3 per unit
3) Bussmann KTK-4 or exact equivalent, 1 per unit
4) Littlefuse KLK-15 or exact equivalent, 1 per unit
5) VLT with standard input option, no brake, no load sharing
5. General Specifications
VLT
®
Automation Drive FC 300
Instruction Manual High Power
124
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
5
