525-690 Volt
VLT Type P400 P500 P560
Output current [VAC] HO NO HO NO HO NO
Continuous (100/ 100%) [A] 550 429 523 523 596 596 630
Intermittent (150/ 110%) [A] 550 644 575 785 656 894 693
Continuous (100/ 100%) [A] 575/ 690 410 500 500 570 570 630
Intermittent (150/ 110%) [A] 575/ 690 615 550 750 627 855 693
Output kVA
Continuous (100/ 100%) [kVA] 550 409 498 498 568 568 600
Intermittent (150/ 110%) [kVA] 550 613 548 747 625 852 660
Continuous (100/ 100%) [kVA] 575 408 498 498 568 568 627
Intermittent (150/ 110%) [kVA] 575 612 548 747 624 852 690
Continuous (100/ 100%) [kVA] 690 490 598 598 681 681 753
Intermittent (150/ 110%) [kVA] 690 735 657 896 749 1022 828
Typical Shaft Output
High Overload (150%) [kW] 550 315 400 450
Normal Overload (110%) [kW] 550 400 450 500
High Overload (150%) [HP] 575 400 500 600
Normal Overload (110%) [HP] 575 500 600 650
High Overload (150%) [kW] 690 400 500 560
Normal Overload (110%) [kW] 690 500 560 630
Max. Motor Cable Length 500 ft (150 m) shielded, 1,000 ft (300 m)
unshielded
Output Voltage [%] 0-100% of the AC line voltage
Output Frequency [Hz] 0-150
Rated Motor Voltage [V] 550/ 575/ 690
Rated Motor Frequency [Hz] 50/60
Thermal protection during
operation
ETR for motor (Class 20)
Thermal protection during
operation
85 85 85
Switching on the Output Unlimited
Ramp times [sec] 0.01 - 3600
VLT
®
Automation Drive FC 300
Instruction Manual High Power
5. General Specifications
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
125
5
