525-690 Volt
VLT Type P400 P500 P560
Max. Input Current [A] 550 413 504 504 574 574 607
Max. Input Current [A] 575 395 482 482 549 549 607
Max. Input Current [A] 690 395 482 482 549 549 607
Max. external pre-fuses
1)
[A]
700 900 900
Soft Charge Fuses
2)
AC [A]
(qty)
20 (3)
SMPS fuse
3)
[A]
4
AC Fan fuse
3)
[A]
4 15
Supply Voltage [V] 3 Phase, 525-690 ± 10%
Supply Frequency [Hz] 50/ 60
Power Factor >0.90 for 525 V
Efficiency 0.98
Power loss at rated max. load (690 V)
High Overload (150%) [W] 5818 7671 8715
Normal Overload (110%) [W] 7249 8727 9673
Enclosure
IP 00, IP 21/ NEMA 1 & IP 54/ NEMA 12
Vibration Test [g] 0.7
Relative Humidity [%] 93%, +2%, -3% (IEC 68-2-3)
Ambient Temperature [de-
grees C]
-10° C to 40° C [14°-104° F] continuously,
periodically at +45° C [113° F]
-25° C to +65°/70° C [-13°-149°/158° F] for
storage/ transport
Adjustable Frequency Drive
Protection
Ground and short-circuit protection
Weight
5)
IP 00/ Chassis [kg]
221 236 277
IP 21/ NEMA 1 [kg] 263 272 313
IP 54/ NEMA 12 [kg]
263 272 313
1) Bussman 170M6000 series. See fuse chart.
2) Bussmann FWH-20A6F or exact equivalent, 3 per unit
3) Bussmann KTK-4 or exact equivalent, 1 per unit
4) Littlefuse KLK-15 or exact equivalent, 1 per unit
5) VLT with standard input option, no brake, no load sharing
