Danfoss VLT FCD 330 Design Guide

VLT
®
FCD Series
Logic or [3]
Dig. input Ser. port Function
0 0 Clockwise
0 1 Anti-clockwise
1
0 Anti-clockwise
1 1 Anti-clockwise
507
507 Selection of Setup
(SETUP SELECT)
Value:
Digital input (DIGIT AL INPUT)
[0]
Serial communication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
✭Logic or (LOGIC OR)
[3]
Function:
See function description of parameter 502 Coasting
stop.
Description of choice:
The table below shows which Setup (parameter 004
Active Setup) is selected for each of the following:
Digital input [0], Serial communication [1], Logic and
[2] or Logic or [3].
Digital input [0]
Setup msb Setup lsb Function
0
0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
Serial communication [1]
Setup msb Setup lsb Function
0 0 Setup 1
0 1 Setup 2
1 0 Setup 3
1 1 Setup 4
Logic and [2]
Bus
Setup
msb
Bus
Setup
lsb
Dig.
Setup
msb
Dig.
Setup
lsb
Setup
no.
0 0 0 0 1
0
0 0 1 1
0
0 1 0 1
0
0 1 1 1
0 1 0 0 1
0
1 0 1 2
0
1 1 0 1
0
1 1 1 2
1
0 0 0 1
1
0 0 1 1
1
0 1 0 3
1
0 1 1 3
1 1 0 0 1
1
1 0 1 2
1
1 1 0 3
1
1 1 1 4
Logic or [3]
Bus
Setup
msb
Bus
Setup
lsb
Dig.
Setup
msb
Dig.
Setup
lsb
Setup
no.
0 0 0 0 1
0
0 0 1 2
0
0 1 0 3
0
0 1 1 4
0 1 0 0 2
0
1 0 1 2
0
1 1 0 4
0
1 1 1 4
1 0 0 0 3
1
0 0 1 4
1
0 1 0 3
1
0 1 1 4
1 1 0 0 4
1
1 0 1 4
1
1 1 0 4
1
1 1 1 4
508
508 Selection of preset ref.
(PRES.REF. SELECT)
Value:
Digital input (DIGIT AL INPUT)
[0]
Serial comunication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
109
Programming
