All about FCD
300
■ Factory settings
PNU
#
Parameter-
description
Factory setting Changes
during
operation
4-setup Conv.
index
Data-
type
100 Configuration Speed reg., open loop No Yes 0 5
101 Torque characteristics Constant torque Yes Yes 0 5
102 Motor power P
M,N
depends on unit No Yes 1 6
103 Motor voltage U
M,N
depends on unit No Yes -2 6
104 Motor frequency f
M,N
50 Hz No Yes -1 6
105 Motor current I
M,N
depends on motor
selected
No Yes -2 7
106 Rated motor speed depends on par. 102 No Yes 0 6
107 Automatic motor adjustment Optimisation off No Yes 0 5
108 Stator resistance R
S
depends on motor
selected
No Yes -3 7
109 Stator reactance X
S
depends on motor
selected
No Yes -2 7
117 Resonance dampening 0 % Yes Yes 0 5
119 High start torque 0.0 sec No Yes -1 5
120 Start delay 0.0 sec No Yes -1 5
121 Start function Coast in start del. No Yes 0 5
122 Function at stop Coast No Yes 0 5
123 Min. freq. for activation of par. 122 0.1 Hz No Yes -1 5
126 DC braking time 10 sec. Yes Yes -1 6
127 DC brake engaging frequency OFF Yes Yes -1 6
128 Thermal motor protection No protection Yes Yes 0 5
130 Start frequency 0.0 Hz No Yes -1 5
131 Voltage at start 0.0 V No Yes -1 6
132 DC brake voltage 0% Yes Yes 0 5
133 Start voltage depends on unit Yes Yes -2 6
134 Load compensation 100 % Yes Yes -1 6
135 U/f-ratio depends on unit Yes Yes -2 6
136 Slip compensation 100 % Yes Yes -1 3
137 DC hold voltage 0% No Yes 0 5
138 Brake cut out value 3.0 Hz Yes Yes -1 6
139 Brake cut in frequency 3.0 Hz Yes Yes -1 6
140 Current, minimum value 0% No Yes 0 5
142 Leak reactance depends on motor
selected
No Yes -3 7
144 AC brake factor 1.30 No Yes -2 5
146 Reset voltage vector Off Yes Yes 0 5
147 Motor type General
MG.04.B7.02 - VLT is a registered Danfoss trademark
119
