Danfoss VLT FCM 311 User Manual

VLT
®
FCM Series
Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parame-
ter No. Function Range/number of settings/value Factory setting
Data
type
Conv.
index
317 Time out 1 -99 sec. 10 sec. 5 0
318 Function after time out Off/Stop and trip Off 5 0
323 X102 relay function 13 No operation 5 0
327 Pulse reference/feedback, max. freq. 100 - 70000 Hz 5000 Hz 7 0
331 Terminal 1, analog input current 3 No operation 6 0
332 Terminal 2, digital input 25 Reference 6 0
333 Terminal 3, digital input 25 Reset 6 0
334 Terminal 4, digital input 24 Start 6 0
335 Terminal 5, digital input 23 Jog 6 0
336 Terminal 1, min. scaling 0.0 - 20.0 mA 0.0 mA 6 -4
337 Terminal 1, max. scaling 0.0 - 20.0 mA 20.0 mA 6 -4
338 Terminal 2, min. scaling 0.0 - 10.0 V 0.0 V 6 -1
339 Terminal 2, max. scaling 0.0 - 10.0 V 10.0 V 6 -1
340 Output functions 21 No operation 6 0
MG.03.H3.02 - VLT is a registered Danfoss trademark
