All about FCM
300
Functions to programme, to control, and to monitor via bus (PROFIBUS) or by PC.
Parame-
ter No. Function Range/number of settings/value Factory setting
Data
type
Conv.
in-
dex
200 Rotation direction 3 Only clockwise 0 - 132 Hz 5 0
201 Min. output frequency
(f
MIN
)
0.0 Hz - f
MAX
0.0 Hz 6 -1
202 Max. output frequency
(f
MAX
)
f
MIN
-f
RANGE
f
RANGE
(132 Hz) 6 -1
203 Reference/feedback
range
Min. - max./-max.- +max. Min. - Max. 5 0
204 Minimum reference -100,000.000 - Ref
MAX
0.000 4 -3
205 Maximum reference Ref
MIN
- 100,000.000 50.000 4 -3
207 Ramp-up time 1 0.05 - 3600.00 sec. 3.00 sec. 7 -2
208 Ramp-down time 1 0.05 - 3600.00 sec. 3.00 sec. 7 -2
209 Ramp-up time 2 0.15 - 3600.00 sec. 3.00 sec 7 -2
210 Ramp-down time 2 0.15 - 3600.00 sec. 3.00 sec 7 -2
211 Jog ramp time 0.05 - 3600.00 sec. 3.00 sec. 7 -2
212 Quick stop ramp-down
time
0.05 - 3600.00 sec. 3.00 sec. 7 -2
213 Jog frequency 0 Hz - f
MAX
10.0 Hz 6 -1
214 Reference function 2 Sum 5 0
215 Preset reference 1 -100.00 % - +100.00 % 0.00 % 3 -2
216 Preset reference 2 -100.00 % - +100.00 % 0.00 % 3 -2
219 Catch up/slow down
value
0.00 - 100.00 % 0.00 % 6 -2
221 Current limit for motor
mode
Min.- max. limit in % of I
rated
Max. limit 6 -1
229 Frequency bypass,
bandwidth
0 (off) - 100 % 0 % 6 0
230 Frequency bypass 1 0.0 - 132 Hz 0.0 Hz 6 -1
231 Frequency bypass 2 0.0 - 132 Hz 0.0 Hz 6 -1
241 Reference preset 1 -100.00 % - +100.00 % 0.00 % 3 -2
242 Reference preset 2 -100.00 % - +100.00 % 0.00 % 3 -2
243 Reference preset 3 -100.00 % - +100.00 % 0.00 % 3 -2
244 Reference preset 4 -100.00 % - +100.00 % 0.00 % 3 -2
245 Reference preset 5 -100.00 % - +100.00 % 0.00 % 3 -2
246 Reference preset 6 -100.00 % - +100.00 % 0.00 % 3 -2
247 Reference preset 7 -100.00 % - +100.00 % 0.00 % 3 -2
MG.03.H3.02 - VLT is a registered Danfoss trademark
99
