Danfoss VLT HVAC Basic Drive FC 101 User Manual

130BT325.10
Figure 3.18 Connecting to Motor for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
311
130BA215.10
RELAY 1
RELAY 2
9
9
6
03 02 01
90 05 04
Figure 3.19 Relays on I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
I7, I8 enclosures
91
L1
92
L2
93
L3
96
U
97
V
98
W
88
DC-
89
DC+
81
R-
8
R+
99
95
130BA248.10
Figure 3.20 I7, I8 Enclosure
IP54, 380-480 V, 45-55 kW (60-70 HP)
IP54, 380-480 V, 75-90 kW (100-125 HP)
Installation Quick Guide
MG18A622 Danfoss A/S © 08/2014 All rights reserved. 17
3 3
