Danfoss VLT HVAC Basic Drive FC 101 User Manual

Circuit breaker Fuse
UL Non-UL UL Non-UL
Bussmann Bussmann Bussmann Bussmann
Maximum
fuse
Power [kW (HP)] Type RK5 Type RK1 Type J Type T Type G
18.5 (25)
Cutler-Hammer
EGE3080FFG
Cutler-Hammer
EGE3080FFG
FRS-R-80 KTN-R80 JKS-80 JJS-80 80
22 (30) FRS-R-80 KTN-R80 JKS-80 JJS-80 80
30 (40) FRS-R-80 KTN-R80 JKS-80 JJS-80 80
37 (50)
Cutler-Hammer
JGE3125FFG
Cutler-Hammer
JGE3125FFG
FRS-R-125 KTN-R125 JKS-125 JJS-125 125
45 (60) FRS-R-125 KTN-R125 JKS-125 JJS-125 125
55 (70) FRS-R-125 KTN-R125 JKS-125 JJS-125 125
75 (100)
Cutler-Hammer
JGE3200FAG
Cutler-Hammer
JGE3200FAG
FRS-R-200 KTN-R200
JKS-200 JJS-200
200
90 (125) FRS-R-200 KTN-R200 JKS-200 JJS-200 200
3x380–480 V IP54
0.75 (1) PKZM0-16 FRS-R-10 KTS-R-10 JKS-10 JJS-10 16
1.5 (2) PKZM0-16 FRS-R-10 KTS-R-10 JKS-10 JJS-10 16
2.2 (3) PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
3 (4) PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
4 (5) PKZM0-16 FRS-R-15 KTS-R-15 JKS-15 JJS-15 16
5.5 (7.5) PKZM0-25 FRS-R-25 KTS-R-25 JKS-25 JJS-25 25
7.5 (10) PKZM0-25 FRS-R-25 KTS-R-25 JKS-25 JJS-25 25
11 (15) PKZM4-63 FRS-R-50 KTS-R-50 JKS-50 JJS-50 63
15 (20) PKZM4-63 FRS-R-50 KTS-R-50 JKS-50 JJS-50 63
18.5 (25) PKZM4-63 FRS-R-80 KTS-R-80 JKS-80 JJS-80 63
22 (30)
Moeller NZMB1-A125
FRS-R-80 KTS-R-80 JKS-80 JJS-80 125
30 (40) FRS-R-125 KTS-R-125 JKS-125 JJS-125 125
37 (50) FRS-R-125 KTS-R-125 JKS-125 JJS-125 125
45 (60)
Moeller NZMB2-A160
FRS-R-125 KTS-R-125 JKS-125 JJS-125 160
55 (70) FRS-R-200 KTS-R-200 JKS-200 JJS-200 160
75 (100)
Moeller NZMB2-A250
FRS-R-200 KTS-R-200 JKS-200 JJS-200 200
90 (125) FRS-R-250 KTS-R-250 JKS-200 JJS-200 200
Table 3.8 Circuit Breakers and Fuses
Installation VLT®HVAC Basic Drive FC 101
20 Danfoss A/S © 08/2014 All rights reserved. MG18A622
