Danfoss VLT HVAC Basic Drive FC 101 User Manual

Adjustable frequency drive P18K P22K P30K P37K P45K P55K P75K P90K
Typical shaft output [kW] 18.5 22.0 30.0 37.0 45.0 55.0 75.0 90.0
Typical shaft output [HP] 25.0 30.0 40.0 50.0 60.0 70.0 100.0 125.0
IP20 frame H5 H5 H6 H6 H6 H7 H7 H8
Maximum cable size in terminals
(line power, motor) [mm
2
(AWG)]
16 (6) 16 (6) 35 (2) 35 (2) 35 (2) 50 (1) 95 (0) 120 (250
MCM)
Output current - 40 °C (104 °F) ambient temperature
Continuous (3x380–440 V) [A] 37.0 42.5 61.0 73.0 90.0 106.0 147.0 177.0
Intermittent (3x380–440 V) [A] 40.7 46.8 67.1 80.3 99.0 116.0 161.0 194.0
Continuous (3x440–480 V) [A] 34.0 40.0 52.0 65.0 80.0 105.0 130.0 160.0
Intermittent (3x440–480 V) [A] 37.4 44.0 57.2 71.5 88.0 115.0 143.0 176.0
Maximum input current
Continuous (3x380–440 V) [A] 35.2 41.5 57.0 70.0 84.0 103.0 140.0 166.0
Intermittent (3x380–440 V) [A] 38.7 45.7 62.7 77.0 92.4 113.0 154.0 182.0
Continuous (3x440–480 V) [A] 29.3 34.6 49.2 60.6 72.5 88.6 120.9 142.7
Intermittent (3x440–480 V) [A] 32.2 38.1 54.1 66.7 79.8 97.5 132.9 157.0
Maximum electrical fuses
Estimated power loss [W],
best case/typical
1)
412/456 475/523 733 922 1067 1133 1733 2141
Weight enclosure IP20 [kg (lb)] 9.5 (20.9) 9.5 (20.9) 24.5 (54) 24.5 (54) 24.5 (54) 36.0 (79.4) 36.0 (79.4) 51.0
(112.4)
Efficiency [%], best case/typical
2)
98.1/97.9 98.1/97.9 97.8 97.7 98 98.2 97.8 97.9
Output current - 50 °C (122 °F) ambient temperature
Continuous (3x380–440 V) [A] 34.1 38.0 48.8 58.4 72.0 74.2 102.9 123.9
Intermittent (3x380–440 V) [A] 37.5 41.8 53.7 64.2 79.2 81.6 113.2 136.3
Continuous (3x440–480 V) [A] 31.3 35.0 41.6 52.0 64.0 73.5 91.0 112.0
Intermittent (3x440–480 V) [A] 34.4 38.5 45.8 57.2 70.4 80.9 100.1 123.2
Table 6.3 3x380–480 V AC, 18.5–90 kW (25–125 HP), Enclosure Type H5–H8
1) Applies for dimensioning of adjustable frequency drive cooling. If the switching frequency is higher than the default setting, the power losses
may increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
www.danfoss.com/vltenergyefficiency.
2) Efficiency measured at nominal current. For energy efficiency class, see chapter 6.4.13 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyefficiency.
Specifications VLT®HVAC Basic Drive FC 101
48 Danfoss A/S © 08/2014 All rights reserved. MG18A622
66
