Adjustable frequency drive P22K P30K P37K P45K P55K P75K P90K
Typical shaft output [kW] 22.0 30.0 37.0 45.0 55.0 75.0 90.0
Typical shaft output [HP] 30.0 40.0 50.0 60.0 70.0 100.0 125.0
IP54 frame I6 I6 I6 I7 I7 I8 I8
Maximum cable size in terminals (line power, motor) [mm
2
(AWG)]
35 (2) 35 (2) 35 (2) 50 (1) 50 (1) 95 (3/0) 120 (4/0)
Output current
40 °C (104 ° F) ambient temperature
Continuous (3x380–440 V) [A] 44.0 61.0 73.0 90.0 106.0 147.0 177.0
Intermittent (3x380–440 V) [A] 48.4 67.1 80.3 99.0 116.6 161.7 194.7
Continuous (3x440–480 V) [A] 40.0 52.0 65.0 80.0 105.0 130.0 160.0
Intermittent (3x440–480 V) [A] 44.0 57.2 71.5 88.0 115.5 143.0 176.0
Maximum input current
Continuous (3x380–440 V) [A] 41.8 57.0 70.3 84.2 102.9 140.3 165.6
Intermittent (3x380–440 V) [A] 46.0 62.7 77.4 92.6 113.1 154.3 182.2
Continuous (3x440–480 V) [A] 36.0 49.2 60.6 72.5 88.6 120.9 142.7
Intermittent (3 x 440–480 V) [A] 39.6 54.1 66.7 79.8 97.5 132.9 157.0
Maximum electrical fuses
Estimated power loss [W], best case/typical
1)
496 734 995 840 1099 1520 1781
Weight enclosure IP54 [kg (lb)] 27 (59.5) 27 (59.5) 27 (59.5) 45 (99.2) 45 (99.2) 65 (143.3) 65 (143.3)
Efficiency [%], best case/typical
2)
98.0 97.8 97.6 98.3 98.2 98.1 98.3
Output current - 50 °C (122 °F) ambient temperature
Continuous (3x380–440 V) [A] 35.2 48.8 58.4 63.0 74.2 102.9 123.9
Intermittent (3x380–440 V) [A] 38.7 53.9 64.2 69.3 81.6 113.2 136.3
Continuous (3x440–480 V) [A] 32.0 41.6 52.0 56.0 73.5 91.0 112.0
Intermittent (3x440–480 V) [A] 35.2 45.8 57.2 61.6 80.9 100.1 123.2
Table 6.5 3x380–480 V AC, 22–90 kW (30–125 HP), Enclosure Type I6–I8
1) Applies for dimensioning of adjustable frequency drive cooling. If the switching frequency is higher than the default setting, the power losses
may increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
www.danfoss.com/vltenergyefficiency.
2) Efficiency measured at nominal current. For energy efficiency class, see chapter 6.4.13 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyefficiency.
