SPECIFICATIONS
MODEL
D2-12C D2-15C
Lifting Capacity 12,000Lbs. / 5,443 Kg. 15,000Lbs. / 6,804 Kg.
Max Capacity/ Front Axle 6,000 lbs. / 2,722 Kg. 7,500 lbs. / 3,408 Kg.
Max Capacity/ Rear Axle 6,000 lbs. / 2,722 Kg. 7,500 lbs. / 3,408 Kg.
A- Height Overall: 168" / 4,285 mm.
(*) 168" / 4,285 mm.
B -Width Overall 155.25" / 3,941 mm. 155.25" / 3,941 mm.
C- Floor to Overhead Switch: 162.75" / 4,131 mm.
(*)
162.75" / 4,131 mm.
D- Arm Reach 31.5” (800 mm) - 58" (1,473 mm) 37.25” (946 mm) - 58” (1,473 mm)
E- Min. Pad Height: 4.25" / 108 mm. 6.5” / 165 mm.
F- Rise: 69" / 1,753 mm. 69" / 1,753 mm.
G - Max Lifting Height: 80” / 2,032 mm 83” / 2,108 mm
I - Width inside Columns: 119.5” / 3,035 mm 119.5” / 3,035 mm
H- Drive-Thru Clearance: 105" / 2,663 mm. 105” / 2,663 mm.
Standard Motor(**) 220 VAC / 60Hz.1Ph. 220 VAC / 60Hz.1Ph.
Time of Full Rise: 55 Seconds 55 Seconds
Max Load Per Arm: 3,000 Lbs." / 1,361 Kg. 3,750 Lbs." / 1,701 Kg.
Emission sound pressure at Operator Position < 70 dB(A)
* An optional bolt-on top extension for column raises the overhead bar an additional 24”. Must be ordered from factory at time of order.
** For CE compliant countries see errata sheet included with control panel.
Specications are subject to change without notice.
D
C
F
G
H
E
I
