STEP 7
(Mounting the Overhead Assembly)
1. Remove all of the Sheaves in preparation of
installing the Overhead Assembly.
2. Using a ForkLift or other lifting device, raise the
Overhead Assembly into position on top of the Columns.
Bolt to the columns using the 10 mm Hex Bolts, Nuts and
Washers.
3. YOU MUST POSITION THE SWITCH ENCLOSURE
ADJACENT POWERSIDE COLUMN. (See Fig. 7.1)
4. Tighten the Overhead Assembly Bolts.
STEP 8
(Mounting the Hydraulic Power Unit)
1. Attach the power unit to the POWER SIDE Column.
Install the vibration dampener between the power unit and
the power unit mounting plate on the Power Side Column,
using four M8 hex head bolts and nuts supplied. (See Fig
8.1)
2. Fill the reservoir with 10 WT. HYDRAULIC OIL OR
DEXRON ATF, approximately four gallons. Make sure the
funnel used to ll the Power Unit and unit is clean.
Do not connect power unit hydraulic hose assembly at
this time.
3. The standard power unit for your lift is 220 VAC, 60HZ,
1PH. All wiring must be performed by a licensed, cer-
tied electrician only. SEE WIRING INSTRUCTIONS
ATTACHED TO MOTOR FOR PROPER WIRING
INSTRUCTIONS.
NOTE:
REMOVE THE CABLE SHEAVES PRIOR TO
EQUALIZER CABLE ROUTING.
IF THE ANCHOR BOLTS WERE LOOSENED TO AID
ON THE INSTALLATION OF THE TOP TROUGH,
TIGHTEN ANCHOR BOLTS AS INDICATED IN STEP
5 ITEMS 4 - 7.
Fig 8.1
Vibration Dampener
M8 x1.25 x 35mm
hex head bolts, M8
at washers and
M8 Nylock nuts
(Qty 4 ea)
DO NOT PERFORM ANY MAINTENANCE OR
INSTALLATION OF ANY COMPONENTS WITHOUT
FIRST ENSURING THAT ELECTRICAL POWER HAS
BEEN DISCONNECTED AT THE SOURCE OR PANEL
AND CANNOT BE RE-ENERGIZED UNTIL ALL
MAINTENANCE AND/OR INSTALLATION
PROCEDURES ARE COMPLETED.
ALL WIRING MUST BE PERFORMED
BY A LICENSED ELECTRICIAN.
Position Overhead
Assembly with microswitch
bracket adjacent to Power
Side Column
Overhead Assembly
Off Side Column
Microswitch Bracket
Power Side Column
Fig 7.1
