D4-9 / D4-9X Four-Post Lifts 11 P/N 5900251 — Rev. A1— August 2021
Model
D4-9 D4-9X
Lifting capacity
9,000 lbs / 4,082 kg
Maximum capacity front axle
4,500 lbs. / 2,041 kg
Maximum capacity rear axle
4,500 lbs. / 2,041 kg
a Total width
1
113 in. / 2,865 mm
a1 Total width (with Power Unit)
125 in. / 3,175 mm
b Outside Posts length
176.5 in. / 4,482 mm 200.5 in. / 5,092 mm
c Total length (includes Ramps)
203 in. / 5,153 mm 227 in. / 5,763 mm
d Post height
89 in. / 2,262 mm 99 in. / 2,516 mm
e Runway thickness
5 in. / 118 mm
f Maximum rise
70 in. / 1,724 mm 82 in. / 2,012 mm
g Maximum lifting height
75 in. / 1,908 mm 87 in. / 2,215 mm
h Distance between Posts
98 in. / 2,490 mm
i Runway width
18.75 in. / 476 mm
j Width between Runways
35 in. / 888 mm
k Runway centerline
53.75 in. / 1,365 mm
l Outside edge of Runways
72.5 in. / 1,842 mm
m Drive-through clearance
86 in. / 2,184 mm
n Length of Runways
165.5 in. / 4,208 mm 189.75 in. / 4,818 mm
Min. wheelbase @ rated capacity
2
115 in. / 2,921 mm 135 in. / 3,429 mm
Min. wheelbase @ 75% capacity
2
100 in. / 2,540 mm 115 in. / 2,921 mm
Min. wheelbase @ 50% capacity
2
85 in. / 2,159 mm 95 in. / 2,413 mm
Min. wheelbase @ 25% capacity
2
70 in. / 1,778 mm 80 in. / 2,032 mm
Locking positions
13; every 4 inches / 102 mm 16; every 4 inches / 102 mm
Lifting time to maximum rise
60 seconds 60 seconds
Motor
110 VAC, 60 Hz, 1 Ph standard; 208-240 VAC available
Sound (when raising/lowering) <70 dBA
1
Make sure to use A value for creating chalk lines, not A1 value.
2
The Lift supports less weight than its full rated capacity if a Vehicle’s wheelbase is shorter because
the Wheels of the Vehicle are closer to the middle of the Runways, where there is less strength. For
example, if you put a Vehicle with a wheelbase of only 84.5 inches on a D4-9, the shorter
wheelbase puts more weight in the middle of the Runways, reducing the Lift’s capacity to
4,500 lbs (50% of its full rated capacity of 9,000 lbs).
Specifications subject to change without notice.
