Dannmar DB-70 - Parts and Diagrams; Cabinet Assembly Parts

DB-70 Automatic Wheel Balancer 54 P/N 5900261 — Rev. A1 — January 2021
Parts
Cabinet Assy
Cabinet Assy. Parts List
# Part Number Description
101 Weight Tray
102 Display Membrane
103 Cross Recessed Pan Head Screw M3 x 25
104 Hex Nut M3
105 Hex Socket Head Screw M6 x 20
106 Spacer
Φ
8
107 5530304 SHCS M8 x 20
108 Washer, Φ8 Split Lock
109 Clip (Reed) Nut, M6
110 SHCS M6 x 25
111 Washer
Φ6
112 Washer, Φ6 Split Lock
113 Hex Nut M6
114 Cabinet
115 Dam-board
116 Cross Recessed Pan Head Screw M4 x 16
117 Display Board
118 5327132 Cone hangar
119 5525251 On-Off switch
