Dannmar DB-70 - Specifications

DB-70 Automatic Wheel Balancer 9 P/N 5900261 — Rev. A1 — January 2021
Specifications Model DB-70
Specifications Performance
Maximum Wheel Weight
150 lbs./68kg
Min.-Max. Rim Diameter
10” – 26” (256 mm – 660 mm)
Min. Max. Wheel Width
1.5”- 20” (38 mm – 508 mm)
Balance Precision
±1g (.035 oz.)
Balance Speed
≈260 rpm
Position Accuracy
1.5
Cycle Time
≈7s
Power Supply
110-230 VAC, 50/60 Hz 1 Ph.* 0.25 kW
Power Cord Length
60” Min. (1524 mm Min.)
Current
.25kW
Drive System Type
Electric Belt Drive
Noise
<70dB
Net Weight
112kg 246 lbs. (No Shaft fixture or external scale)
Gross Weight
308.7 lbs. / 140kg
Dimensions
48.4 in. wide by 41.3 in. deep by 54.3 in. high
1230 mm wide by 1050 mm deep by 1380 mm high
Operating Temperature
41º F to 122º F / +5º to +50ºC
Relative humidity
85% Non-Condensing
*Comes from the factory configured for 110 VAC operation. The Balancer may be switched to 220
VAC. Refer to Connecting to Power for instructions; Licensed Electrician is required to switch the
Balancer to 220 VAC.
Specifications subject to change without notice.
