PAGE 4 46210/46220-0998 <90-00036>
INSTALLATION
T
his chapter consists of four sections: equipment mounting,
switch and strap settings, wiring, and checkout. Follow the
sections in order.
WARNING: Remove fuse F1 before plugging a live power connector into
TB1. Plugging in a live connector without removing the fuse,
may damage the unit. Reinstall the fuse after plugging in the
connector.
EQUIPMENT MOUNTING
Install the 46210/46220 in an equipment rack or distribution
frame.
SELECTING A LOCATION
♦ Select a location at least two feet above the floor.
♦ Provide at least 3.5 inches of clearance above the unit.
♦ Provide at least 1.75 inches of clearance below the unit.
If it is not possible to meet the criteria above, refer to Installa-
tion in Limited Space in this chapter.
TOOLS REQUIRED
Installing the 46210/46220 unit may require one or more of the
following tools:
♦ Phillips screwdriver
♦ Small standard screwdriver
♦ 11/32-inch wrench
EQUIPMENT RACK MOUNTING
The 46210/46220 attaches to a mounting bar on the equipment
rack. Mounting bars can be ordered from Dantel. Refer to the
Ordering Information section of this manual.
Each mounting bar holds two units.
To install:
1. Attach the carriage bolts to the unit with the retaining clips (refer
to Fig. 2).
2. Attach the unit to the mounting bar with the locking hex nuts. Use
mounting holes A, B, C, and D. Refer to Figs. 2 and 3.
3. Attach the mounting bar to the equipment rack (hardware not sup-
plied).
4. Equipment rack mounting complete.
