46210/46220-0998 <90-00036> PAGE 41
A report also will be issued if one of the alarm status input
modules inside the 46210/46220 is removed or disconnected.
Example:
>SG 8 OFF LINE
The example above shows a failure of alarms 113 through 128
(subgroup 8). When the subgroup returns to operation, another
report will be issued showing the subgroup on line.
Example:
>SG 8 ON LINE
INPUT COMMANDS
Alarm inputs are divided into subgroups of 16 alarm points
each. When referring to alarms, the term “MAT” or the term
“SG” (for SubGroup) may be used. They both refer to the same
thing: a group of alarm inputs (refer to Table F). The MAT is a
Multiple Alarm Transmitter module, which is not part of the
46210/46220. The commands that are used for the MAT, how-
ever, also work with the 46210/46220. The 46210 has 16 sub-
groups of alarms. The 46220-00 has eight subgroups of alarms.
The 46220-01 has 12 subgroups.
Control points also are divided into subgroups of 16 points each
(the same as alarm subgroups 1-4 in Table F). The dumb termi-
nal uses the term “CPM” when referring to control points. The
CPM is a Control Point Module, which is not part of the 46220.
But the commands for the CPM also work with the 46220. The
46220-00 has four subgroups. The 46220-01 has two subgroups.
TABLE F - ALARM POINTS WITHIN SUBGROUPS
PRINTER SYNTAX
SREBMUNTNIOPMRALA REBMUNPUORGBUS SREBMUNTNIOPMRALA REBMUNPUORGBUS
61hguorht1 1 441hguorht921 9
23hguorht71 2 061hguorht541 01
84hguorht33 3 671hguorht161 11
46hguorht94 4 291hguorht771 21
08hguorht56 5 802hguorht391 31
69hguorht18 6 422hguorht902 41
211hguorht79 7 042hguorht522 51
821hguorht311 8 652hguorht142 61
