FIG. 5 - SEPARATING 46210/46220 FROM MOUNTING CHASSIS
INSTALLATION
462xx-xx REV ____
WARNING:
REMOVE fuse
before removing
or inserting module
Use wrist strap
ESD SENSITIVE DEVICE
POWER
ALARM
uP LED
MSTR AUX
GREEN = RCV
RED = XMT
Front View
Mounting Chassis
Unit
