PRODUCT OVERVIEW
Communication Ports
RJ12
RS485 S RS485 MRJ45
Dip Switches
Distribution Box
Grid
on
off
Load
on
off
By pass
on
off
PV Input
Grid Input
Load Ouput
AC Input II
(Optional)
Basic Hybrid PV Storage System
RS-485 PIN
DEFINITIONS
RS485 S
RS485 M
1
2
3
4
1
2
3
4
D+
D-
D+
D-
D+
D-
D+
D-
PORT
FUNCTION
RJ45
For H200 External Display
RJ12 (x2)
For Parallel (Stacking) Function
RS485 S (Pin 1&2)
For Data Logger and Remote Access
Dip Switches
For Long Distance Cable Communication
RS485 M (Pin 1&2)
For Battery BMS and Meter
25mm (1.0in)
514mm (20.2in)
150mm (5.9in)
858mm (33.8in)
181mm (7.1in)
