DAS Action Series - Action 500 Series Model Introductions; Full-Range Models Overview

INTRODUCTION
ACTION-512A
-Two-way powered system.
-12” bass loudspeaker, 12MI4 (2,5" VCD).
-Compressor driver with titanium diaphragm, M-34 (1,4" VCD).
-Asimetric encolusure design for stage monitor use.
-Built-in rigging points (eyebolt based).
-Stand mountable.
The ACTION-512A is a powered loudspeaker (2 channel Class D
amplifier), that utilizes a 12” low frequency transducer and a 1” exit
compression driver. The multi-angle cabinet is constructed of Birch plywood
protected by an environmentally friendly black paint finish. Two bar handles
and a steel grille are provided. A 35mm tripod socket with angle double (0º
and -10º) allows for stand mounting.
ACTION-M512A
-Dedicated powered stage monitor.
-12” bass loudspeaker, 12MI4 (2,5" VCD).
-Compression driver with titanium diaphragm, M-34 (1,4" VCD).
-Low profile enclosure design for minimum visual impact.
-Black paint finish.
-Stand mountable.
The ACTION-M512A is a dedicated powered stage monitor (2channel
Class D amplifier). The enclosure ir constructed from Birch plywood and is
protected with a black paint finish. Two side located handles facilitate
handling and a steel grille protects the components. A pole mount socket
adds versatility to the ACTION-M512A.
Settings
The action 500 series inherits the exceptional sound quality and rugged build that have made DAS
professional systems an internacional sound reinforcement standard. Designed from “real-world” experience,
they offer users outstanding performance, absolute reliability, and unparalleled convenience. Whether it is in a
high-profile venue or on the stage of a major event, the action 500 series will provide the power and definition
needed to make your performance a success.
6
ACTION-508A
- Compact multi-purpose system with monitor position
- 8” bass loudspeaker, 8GV (1,5" VCD).
- Compressor driver with titanium diaphragm, M-34 (1,4" VCD).
- Reduces size and weight
- Pole mount socket
The ACTION-508A offers a multi-angle enclosure which allows it to
be used in stage monitor applications as well as a compact P.A.
system. The 720 W peak power of the Class D amplifier provides
extended bandwith, improved dynamic range and exceptionally low
distortion-features hard to find on other systems in this market segment.
The 8GV loudspeaker provides accurate low frequency reproduction.
High frequencies are handled by the M-34 compression driver with 1”
exit and titanium diaphragm offering excellent performance.
ACTION-515A
-Two-way powered system
-15” bass loudspeaker, 15MI4 (2,5" VCD)
-Compression driver with titanium diaphragm, M-34 (1,4" VCD)
-Asymmetric enclosure design for stage monitor use
-Built-in rigging points (eyebolt bassed)
-Stand mountable
ACTION-515A is a powered loudspeaker (2 channel Class D amplifier),
uses a 15” low frequency transducer and a 1” exit compression driver with
titanium diaphragm. The cabinet is constructed from Birch plywood and
finished with an envinonmentally friendly black paint finish. Two bar handles
are provided and a steel grille protects components. A 35mm tripod socket
with angle double (0º and -10º) allows for stand mounting. Rigging points
provide a safe and simple solution for suspending the ACTION-515A
Manual del Usuario / action 500 series / User’s Manual
