WARNING
System installation
Voltage rating (as the picture)
1）This product is designed for vehicles with a 12V battery and negative GND.
Before installation, check the battery voltage.
2）To prevent short-circuiting the system, it is recommended to disconnect the
battery negative terminal before installation.
3）Do not bypass the device fuse, connect it directly to the battery.
The installation of the device
1) First of all, remove the original vehicle stereo.
2）Take out the installation bracket and screws and set them aside.
3）Securely attach the bracket to the navigation system device using the pro-
vided screws.
4) Avoid directly connecting the power wire of this product to other power-line
circuits.
5) Organize and route all cables according to the hose diagram.
6) Install the navigation system in the correct position, then securely fasten
the original car bracket with screws to ensure a stable fit.
Note:Do not damage or dirty the Dashboard.
