Low Decibel Fluid Cooler Selection Chart
All selections based on 40% glycol
Ambient Temperature
95 100 105
1
Fluid PD Fluid PD Fluid PD
Model THR GPM Cooler MBH (FT) Cooler MBH (FT) Cooler MBH (FT)
Mini Ceiling
DAM* 01 15 3.5 DAFC 06 30 0.2 DAFC 06 24 0.2 DAFC 06 18 0.2
DAM* 1.5 23 5.3 DAFC 06 36 0.5 DAFC 06 29 0.5 DAFC 07 26 0.6
DAM* 02 30 7.0 DAFC 06 49 1.1 DAFC 06 37 1.1 DAFC 09 34 1.6
DAM* 2.5 36 8.8 DAFC 06 57 1.6 DAFC 06 42 1.6 DAFC 17 40 0.2
Mini Plus
DAP* 2.5 39 8.8 DAFC 06 57 1.6 DAFC 06 42 1.6 DAFC 17 40 0.2
DAP* 03 49 10.5 DAFC 06 63 2.2 DAFC 07 52 2.8 DAFC 24 52 0.3
DAP* 04 69 14.0 DAFC 06 72 3.7 DAFC 21 74 0.6 DAFC 28** 66 0.3
DAP* 05 83 17.5 DAFC 07 89 7.1 DAFC 21 102 1.4 DAFC 30 90 1.8
Large Ceiling Units - Single or Dual Compressor
DAL* 06 104 21.0 DAFC 11 104 3.0 DAFC 21 116 2.0 DAFC 37 105 1.4
DAL* 08 136 28.0 DAFC 21 170 3.3 DAFC 28 146 1.3 DAFC 44 144 2.8
DAL* 10 188 35.0 DAFC 21 188 5.0 DAFC 37 195 3.5 DAFC 50 172 2.9
DAL* 13 225 45.0 DAFC 28 230 3.1 DAFC 40 229 3.9 DAFC 88 244 1.9
Data Temp
DT*D/U 02 33 7.0 DAFC 06 49 1.1 DAFC 06 37 1.1 DAFC 09 34 1.6
DT*D/U 03 49 10.5 DAFC 06 63 2.2 DAFC 07 52 2.8 DAFC 24 52 0.3
DT*D/U 04 69 14.0 DAFC 06 72 3.7 DAFC 21 74 0.6 DAFC 28** 66 0.3
DT*D/U 05 83 17.5 DAFC 07 89 7.1 DAFC 21 102 1.4 DAFC 30 90 1.8
Modular Data Temp
DT*D/U 08 135 28.0 DAFC 21 170 2.3 DAFC 28 146 1.3 DAFC 44 144 2.8
DT*D/U 10 172 35.0 DAFC 21 188 5.0 DAFC 30 185 6.2 DAFC 50** 172 2.9
DT*D/U 13 226 46.0 DAFC 28 230 3.1 DAFC 40 229 3.9 DAFC 88 244 1.9
Data Aire Series
DA*D/U 06 100 21.0 DAFC 11 104 3.0 DAFC 21 116 2.0 DAFC 30 103 2.5
DA*D/U 08 143 28.0 DAFC 21 170 3.3 DAFC 28 146 1.3 DAFC 44 144 2.8
DA*D/U 10 161 35.0 DAFC 21 188 5.0 DAFC 30 185 6.2 DAFC 50 172 2.9
DA*D/U 13 224 45.0 DAFC 28 230 3.1 DAFC 40 229 3.9 DAFC 88 244 1.9
DA*D/U 16 247 56.0 DAFC 30 277 14.4 DAFC 44 283 9.6 DAFC 75 258 2.3
DA*D/U 20 326 70.0 DAFC 40 331 8.4 DAFC 57 331 1.9 DAFC 88 336 4.1
DA*D/U 26 395 91.0 DAFC 44 405 23.1 DAFC 61 417 9.9 DAFC 100 402 4.6
DA*D/U 30 484 105.0 DAFC 61 543 12.8 DAFC 80 484 5.0 N/A N/A N/A
gForce GT
GT*D/U007 33 7.0 DAFC 06 49 1.1 DAFC 06 37 1.1 DAFC 09 34 1.6
GT*D/U011 49 10.5 DAFC 06 63 2.2 DAFC 07 52 2.8 DAFC 24 52 0.3
GT*D/U014 69 14.0 DAFC 06 72 3.7 DAFC 21 74 0.6 DAFC 28** 66 0.3
GT*D/U018 83 17.5 DAFC 07 89 7.1 DAFC 21 102 1.4 DAFC 30 90 1.8
gForce
GF*D/U021 100 21.0 DAFC 11 104 3.0 DAFC 21 116 2.0 DAFC 30 103 2.5
GF*D/U028 143 28.0 DAFC 21 170 3.3 DAFC 28 146 1.3 DAFC 44 144 2.8
GF*D/U035 161 35.0 DAFC 21 188 5.0 DAFC 30 185 6.2 DAFC 50 172 2.9
GF*D/U046 224 45.0 DAFC 28 230 3.1 DAFC 40 229 3.9 DAFC 88 244 1.9
GF*D/U056 247 56.0 DAFC 30 277 14.4 DAFC 44 283 9.6 DAFC 75 258 2.3
GF*D/U070 326 70.0 DAFC 40 331 8.4 DAFC 57 331 1.9 DAFC 88 336 4.1
GF*D/U091 395 91.0 DAFC 44 405 23.1 DAFC 61 417 9.9 DAFC 100 402 4.6
GF*D/U106 484 105.0 DAFC 61 543 12.8 DAFC 80 484 5.0 N/A N/A N/A
* Insert: W - Water or G - Glycol
** The capacity of the selected uid cooler is less than the total heat rejection (THR) specied for the given
unit. The result will be slightly higher water temperatures which can cause a small decrease in unit capacity.
1
Fluid coolers are not recommended for higher ambient temperatures.
