10
DAFC Fluid Cooler Capacity Breakdown
Based on 40% Glycol
DAFC 06 DAFC 07 DAFC 09 DAFC 11 DAFC 15 DAFC 17 DAFC 21
GPM MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD
5 36.9/.04 41.7/.05
10 61.0/2.0 69.2/2.6 72.0/3.1
15 73.9/4.2 83.7/5.4 90.6/6.5
20 82.0/7.1 92.4/9.0 99.5/10.9 101.6/2.7
25 86.2/10.6 97.0/13.4 112.8/4.1 172.6/2.7
30 121.5/5.7 143.6/2.9 191.2/3.8
35 126.7/7.5 152.8/3.8 206.8/5.0
40 132.1/9.5 160.1/4.8 171.7/2.7 220.4/6.4
45 136.7/11.8 166.0/6.0 178.7/3.4 231.5/7.9
50 140.6/14.2 168.9/7.2 184.5/4.1 237.5/9.5
55 173.0/8.6 189.4/4.8 244.7/11.3
60 176.5/10.1 193.4/5.7 250.9/13.2
65 179.5/11.6 196.7/6.5
70 182.2/13.3 198.0/7.5
75 200.5/8.5
80 202.8/9.5
85 204.9/10.6
100 206.7/11.8
DAFC 24 DAFC 28 DAFC 30 DAFC 37 DAFC 40 DAFC 44 DAFC 50
GPM MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD MBH/PD
30 229.7/4.7 229.7/4.7
35 219.2/2.8 251.5/6.2 251.5/6.2 298.4/4.1 305.6/2.9
40 233.9/3.9 244.2/2.5 270.7/7.9 285.1/4.4 295.8/3.1 325.9/5.3 336.1/3.6
45 246.4/4.4 257.6/3.1 286.7/9.7 303.0/5.5 315.3/3.8 349.8/6.5 362.5/4.5
50 257.4/5.3 268.9/3.7 296.5/11.7 318.9/6.6 331.4/4.6 370.5/7.9 385.4/5.5
55 267.0/6.3 278.7/4.4 307.3/13.9 332.9/7.8 345.7/5.4 388.6/9.3 405.3/6.5
60 275.1/7.4 287.3/5.1 344.9/9.2 358.5/6.3 404.6/10.9 422.8/7.6
65 281.2/8.6 294.9/5.9 354.3/10.6 369.8/7.3 418.8/12.6 438.0/8.7
70 284.3/9.8 301.6/6.8 359.7/12.1 379.7/8.4 429.0/14.4 451.5/10.0
75 289.0/11.1 307.1/7.7 367.0/13.7 388.1/9.5 463.5/11.3
80 293.2/12.4 311.3/8.6 394.7/10.4 474.3/12.7
85 297.0/13.9 313.1/9.6 398.0/11.9 481.5/14.2
90 316.5/10.7 400.3/13.2
** Continued on next page **
