Data Aire DAFC User Manual

9
Indoor Fluid Cooler Selection Chart
95° Ambient
Model THR GPM Fluid Cooler MBH PD
Data Temp
DT*D/U-02 36 7.0 DAFC-06-PB 49 1.1
DT*D/U-03 49 10.5 DAFC-06-PB 63 2.2
DT*D/U-04 72 12.0 DAFC-07-PB 81 4.7
DT*D/U-05 88 17.5 DAFC-07-PB 89 7.1
Modular Data Temp
DT*D/U-08 136 28.0 DAFC-15-PB 139 2.5
DT*D/U-10 172 35.0 No Selection
DT*D/U-13 224 46.0 No Selection
Data Aire Series
DA*D/U-06 100 21.0 DAFC-11-PB 104 3.0
DA*D/U-08 146 28.0 DAFC-17-PB 148 1.4
DA*D/U-10 162 35.0 DAFC-17-PB 163 2.1
DA*D/U-13 224 46.0 No Selection
DA*D/U-16 245 56.0 No Selection
DA*D/U-20 310 70.0 No Selection
DA*D/U-26 387 91.0 No Selection
DA*D/U-30 482 105.0 No Selection
* Insert W - Water, G-Glycol
All selections are based on the following conditions:
40% glycol, 125° condensing temperature and 115° uid temperature
DAFC-PB Indoor Fluid Cooler
Electrical Data
Model Motor HP 208-230/3/60* 460/3/60*
DAFC-06-PB 3 9/11/20 4.4/5.5/15
DAFC-07-PB 3 9/11/20 4.4/5.5/15
DAFC-09-PB 3 9/11/20 4.5/5.5/15
DAFC-11-PB 7.5 23/28/50 11/14/20
DAFC-15-PB 7.5 23/28/50 11/14/20
DAFC-17-PB 7.5 23/28/50 11/14/20
DAFC-21-PB 3 27/24/60 13/17/25
DAFC-21-PB 3 27/24/60 13/17/25
DAFC-28-PB 3 27/24/60 13/17/25
* FLA/MCA/MOP (FLA -Full load amps, MCA-Minimum circuit amps wire sizing amps, MOP-Maximum over-
current protection device amp.)
