CBX800 INSTALLATION MANUAL
9
PINOUT
Pinouts
Group
Name
Function
Input Power
Vdc
Power Supply Input Voltage +
GND
Power Supply Input Voltage -
Earth
Protection Earth Ground
External
Trigger Input
+V
Power Source – External Trigger
I1A
External Trigger A (polarity insensitive)
I1B
External Trigger B (polarity insensitive)
-V
Power Reference – External Trigger
Generic Input
+V
Power Source – Inputs
I2A
Input 2A (polarity insensitive)
I2B
Input 2B (polarity insensitive)
-V
Power Reference – Inputs
Outputs
+V
Power Source – Outputs
-V
Power Reference – Outputs
O1+
Output 1+
O1-
Output 1-
O2+
Output 2+
O2-
Output 2-
Other I/O
O3A
Output 3+ (polarity sensitive)
O3B
Output 3- (polarity sensitive)
+V
Power Source – Other I/O
I3A
Input 3A (polarity insensitive)
I4A
Input 4A (polarity insensitive)
-V
Power Reference – Other I/O
I34B
Input 3B and 4B (common) (polarity insensitive)
I34B
Input 3B and 4B (common) (polarity insensitive)
Auxiliary
Interface
(1)
TX
Auxiliary Interface TX
RX
Auxiliary Interface RX
SGND
Auxiliary Interface Reference
ID-NET™
REF
Network Reference
ID+
ID-NET™ network +
ID-
ID-NET™ network -
Network
Shield
Network Cable Shield
Data Source
Auxiliary
Interface
(2)
TX
Data Source Aux TX
RX
Data Source Aux RX
SGND
Data Source Aux Reference
Data Source
Interface
RS232
RS485FD
RS485HD
TX
TX+
RTX+
RTS
TX-
RTX-
RX
*RX+
CTS
*RX-
SGND
SGND
SGND
Host Interface
RS232
RS485FD
RS485HD
TX
TX+
RTX+
RTS
TX-
RTX-
RX
*RX+
CTS
*RX-
SGND
SGND
SGND
* Do not leave floating, see Reading Device Reference Manual for connection details.
(1)
The Auxiliary Interface group is connected to the 9-pin Auxiliary connector and is used for configuring the
CBX800 parameters through Genius™, the multilanguage software tool.
(2)
The Data Source Auxiliary group is connected to the 9-pin Data Source connector and is used for configuring
Genius-compatible reading devices through Genius™, the multilanguage software tool.
