CBX800 INSTALLATION MANUAL
OPENING THE CBX800
To install the CBX800 or during normal maintenance, it is necessary to open it by unscrewing the four cover
screws:
The CBX800 must be disconnected from the power supply during this operation.
ACCESS TO INTERNAL PARTS
To make installation and replacement easier, the CBX800 is made up of three parts:
1) the body of the device containing all electronic components and optional boards
2) the transparent removable cover for inspection and for easy access to spring clamps and internal
modules
3) the removable front connector panel providing easy access to the optional interface modules
Figure 2 – CBX800 Front Connector Panel
