CBX800 INSTALLATION MANUAL
ACCESSORIES
The following accessories are available on request for the CBX800:
Ethernet TCP/IP Module STD/IP65
Ethernet/IP Module STD/IP65/IP54
93ACC1812, 93ACC1813,
93ACC1840
M12 3P F Connector Panel (Service)
M12 3P M Connector Panel (External Power)
M12 4P F Connector Panel (Trigger)
M12 5P F Connector Panel (ID-NET™ Out)
M12 5P M Connector Panel (ID-NET™ In)
Gender Changer 25P M/M (5 pcs)
SUPPORTED READING DEVICES
The CBX800 can be directly connected to all of the following readers through the 25-pin connector illustrated in
Figure A.
CBX800 is backward compatible with DS2100N/DS2400N (black body), DS4600A, and
DS1100/DS2200 10-30 Vdc model reading devices using the ADP-MM1 25-pin gender
changer. See the Gender Changer documentation for the relative CBX pinout.
For 6/8K family scanners having software version 6.80 or later, an alternative fixed speed
(57600 baud) ID-NET™ layout can be made without the use of CBX800. See the ID-NET™
Application Note on the downloadable Genius mini-DVD file for details.
For maximum ID-NET™ network performance use CBX800.
A Hand-Held reader can also be connected to the 25-pin connector and have its data passed through to the Host or
ID-NET network.
