CBX800
INSTALLATION MANUAL
Figure A
Indicator LEDs
1
Cover Screws (4)
2
Compression Connectors (5)
4
25-pin Device Connector
5
Host Interface Module Panel
3
NOTE
For a complete Gateway configuration using the Genius™ configuration program, refer to the
CBX800 Help On-Line available on the downloadable Genius CD zip file. This manual is also
downloadable from the Web at www.datalogic.com.
13/07/17
5
1
2
4
3
