CBX800 INSTALLATION MANUAL
2
Figure B
13
1
6
7
9
10
12
7
15
14
8
2
3
4
11
5
16
11
Power switch (ON/OFF)
1
2
Source Chassis Grounding Selector
3
Source Shield Selector
5
4
Power Source Selector
Mounting Holes (2)
6
Data Source Port Connector
Indicator LEDs
7
Auxiliary Port Connector
8
IP65 Host Interface Module Connector
9
Standard Host Interface Module Connector
11
Spring Clamp Terminal Blocks
12
RS485 Termination Resistance Switch
13
ID-NET/Host Shield Selector
14
ID-NET Termination Resistance Switch
15
Network Selection Rotary Switches
16
Reset Button
10

Datalogic BA100 Specifications

General

Brand	Datalogic
Model	BA100
Category	Adapter
Language	English
