CBX500
INSTALLATION MANUAL
Figure A
821001384 (Rev. D)
5
1
2
4
3
1
2
3
4
5
Indicator LEDs
Cover Screws (4)
Host Interface Module Panel
Compression Connectors (5)
25-pin Device Connector
